USING YOUR EXPLODED ILLUSTRATION

This Exploded Illustration shows the information about the parts of Tape Feeder for

SIGMA-G4/G5 and is made for Parts Ordering.

You must not replace a part with a new one according to only the information of this

Exploded Illustration.

1. Inquiring

For identiﬁcation of each part, numbers are placed on illustration pages. These

numbers (Key No.) again appear in the far left column of the part table joined up

with the illustration.

The number shown in the Q’ty column of the part table represents the quantity of

certain part used in the equipment. In case of unit assembly, however, the number

represents the quantity of certain part contained in single unit.

2. Parts Ordering

For ordering parts, some parts might not be supplied as a single item, due to the

constitution of such parts.

When ordering parts, be sure to inform us of the following details:



Model

ype



Serial No.



Fig. No.



Key No.



PART No.



T NAME



Quantity

[Example]

3. Miscellaneous

This Exploded Illustration is subject to change without prior notice.

This Exploded Illustration shall not in any shape or form, in whole or part, be

reproduced, copied or disclosed to any third party without the written content

of the publisher.

'' NOTE '' is used to show the notice that is not directly related to safety.

Some of the parts shown in the Exploded Illustration could fall into the scope of your

government’

s regulations on strategic products. In that case, anybody who intend to

export the product should acquire due authorization.

GT-28080

Model Type

GT28080 7890

Serial No.

Key No.24

Key No.

226J1909

PART No.

Q'ty

Fig. No.

Fig. W-1

PART NAME

CUTTER

USING

・・・

0912-002

CONTENTS-1

4mm Tape Feeder

Fig. D

テープフィーダ

GT-24040

Tape Feeder GT-24040

8mm Tape Feeder

Fig. W

テープフィーダ

GT-28080,28082

Tape Feeder GT-28080,28082

Fig. WD

継ぎ目検出ユニット

DS-28080

Joint Detection Unit DS-28080

Fig. M

テープフィーダ

GD-28081,28083

Tape Feeder GD-28081,28083

12,16mm Tape Feeder

Fig. G

テープフィーダ

-12162

Tape Feeder GT-12162

Fig. GD

継ぎ目検出ユニット

DS-12162

Joint Detection Unit DS-12162

24,32mm T

ape Feeder

Fig. P

テープフィーダ

GT-24322

Tape Feeder GT-24322

Fig. PD

継ぎ目検出ユニット

DS-24322

Joint Detection Unit DS-24322

44,56mm T

ape Feeder

Fig. Q

テープフィーダ

GT-44562

Tape Feeder GT-44562

Fig. QD

継ぎ目検出ユニット

DS-44562

Joint Detection Unit DS-44562

CONTENTS-1

CONTENTS

CONTENTS-2

72mm Tape Feeder

Fig. T 72mm

テープフィーダ

GT-72002

72mm Tape Feeder GT-72002

Fig. TD

継ぎ目検出ユニット

DS-72002

Joint Detection Unit DS-72002

88mm T

ape Feeder

Fig. X 88mm

テープフィーダ

GT-88002

88mm Tape Feeder GT-88002

Fig. XD

継ぎ目検出ユニット

DS-88002

Joint Detection Unit DS-88002

1011-004

CONTENTS-2
