Station Software 706.0 / Installation Manual Ausgabe 04/2012 Edition
2 Scope of delivery
2.1 Software components
706.0 software
Standard package: 00140040-01 Software SIPLACE Station 706.0 Basic
– Software CD-ROM
(1)
– Software DVD SIPLACE Smart GUI
– License/product certificate
– Software Installation Manual V706.0 D+E (00197044-01)
– Packaging
Languages: 00140041-01 SIPLACE foreign language software SC 706.0
– CD-ROM with software (language pack)
– License/product certificate
– Software Version Description for foreign languages V706.0 D+E (00197045-01)
– Packaging
(1)
The standard applications are contained on the CD:
– Embedded software for conveyor
– Embedded software for axes
– Embedded software for component tables
– Embedded software for tape cutter
– Embedded software for heads
– Embedded software for vision modules
– Embedded software for I/O modules
– Embedded software for X-feeders
– Embedded software for digital pressure regulation valve
– Embedded software for MTC2
– Embedded software for WPC5/WPC6
2.2 Hardware components
– Machine computer
– Vision computer (optional)
– Coplan computer (optional)
6
Station Software 706.0 / Installation Manual Ausgabe 04/2012 Edition
2.3 Languages
SIPLACE Station and SIPLACE Vision GUI:
The standard package contains German, English and Simplified Chinese versions. As for
Simplified Chinese a preliminary version is provided.
The final version of Simplified Chinese and other languages contained in the languages package
are optional and available under the item number 00140041-01.
The following table indicates which languages are available for the station software and SIPLACE
Vision:
Language Station software / SIPLACE
Vision
French x
Italian x
Spanish (Mexico) x
Portuguese (Brazil) x
Czech
*)
x
Polish
*)
x
Hungarian x
Romanian
*)
x
Chinese (simplified) x
Korean x
Japanese x
Table 2-1: Languages
*)
GUI only (online help English)
7
Station Software 706.0 / Installation Manual Ausgabe 04/2012 Edition
3 Upgrading to the 706.0 software version
This chapter describes which steps you have to attend when upgrading from different software
versions.
When upgrading the station software, always check the eSW versions and download the current
versions if necessary.
3.1 Upgrading from the 705.xx software version
► SX1/SX2 and DX1/DX2 placement machines in the field with an FC camera at Location 1:
Due to an error correction in the configuration, the FC camera position has been moved and
thus the calibration values for the camera and the segment offset are invalid.
Recalibrate the camera and the segment offset.
3.2 Upgrading from the 704.xx software version
NOTICE
– With the installation of the 706.0 station software, statistic data (maintenance
intervals) is registered for the CPP and C&P20A placement heads and the SX main
axis. In order to achieve a defined initial state for the maintenance due, the
correspondent maintenance operations have to be performed on the subsystems
after the software installation.
– An upgrade of the embedded software is necessary for the LDU-X. Generally, it is
not possible to perform a download of the embedded software via the station
software for the LDU-X. The LDU-X has to be upgraded to the 2.02 software version
with the aid of an external PC.
► SX1/SX2 placement machines in the field with an FC camera at Location 1:
Due to an error correction in the configuration, the FC camera position has been moved and
thus the calibration values for the camera and the segment offset are invalid.
Recalibrate the camera and the segment offset.
► Recalibrate the external cameras.
This is required, as the z height has been adapted for the dp calibration.
► Save the calibration data for the placement heads (except Twin Head) in the EEPROM
(see section 7.9).
► Perform a component sensor calibration if a CPP placement head is used for 0201/01005
placement.
