Existing Restrictions
Technical Restrictions
34 SIPLACE Traceability 3.6 SP1
▪ The following maximum lengths (characters) for the PCB barcode are available if the PCB barcode
is read in the SIPLACE machine:
▪ The length of the setup name is limited to 20-50 characters, i.e. only the first 20 to 50 characters will
be taken into account during setup changeovers.
▪ The unique ID for a packaging unit may have a maximum of 40 characters.
▪ If you change the configuration of the Traceability system the SIPLACE line has to be empty. Other
-
wise Traceability data may be incomplete.
▪ Station based and line based traceability cannot run simultaneously in the same line.
▪ If a station is part of several lines (SIPLACE Pro configuration), there are the following restrictions
for line based traceability:
– Only one of the lines may be active at the same time.
– If an external PCB barcode reader is allocated to more than one line then the PCB barcodes are
assigned to the line which is active in Trace Service. If there are multiple lines active with the
same external barcode reader, Trace Service will issue an error message. Traceability data can
not be reliably generated in this case.
▪ In case of line based traceability the sequence of the boards may only be changed (e.g. by a pro
-
ductivity lift) if there are external PCB barcode readers in front of AND at the end of the line.
▪ The option "Remove unused charges" in the TraceService Monitor requires that you perform forced
setup verification for all the lines for which traceability data are to be generated in "line-based" mode.
For 407
▪ When using a synchronous dual conveyor, traceability data can only be generated to a limited de
-
gree. The restriction is based on the fact that both boards are seen as one panel and that the trace
-
ability data is therefore stored in one data package. The board barcode used is always the barcode
read at conveyor 1.
5.2
5.2 Technical Restrictions
Technical Restrictions
▪ Network connection
To enable SIPLACE Trace Service to import the traceability data from stations with station software
<70x, you need to configure the relevant network connections. The non-availability of configured im
-
port paths and network connections is recorded in the log file.
▪ We recommend that you limit the size of the Trace database to 20 GB. If the database has reached
this size, it should be archived in a backup and the production should be continued with a newly cre
-
ated Trace database.
Station software Single conveyor Synchronous dual convey
-
or
Asynchronous dual convey
-
or
407 / 505 / 605 / 70x 40 characters 40 characters / 40 charac
-
ters
40 characters
From SiplacePro 11.2
and 707.1
255 characters 255 characters / 255 char
-
acters
255 characters
Station software Max. length of setup names
407 20 characters exc. path
505 50 characters exc. path
605 256 characters inc. path
70x 256 characters inc. path
NOTICE
Station and line name
The station name must be unique in the line. The line name must be unique throughout the
traceability system.
Annex
Overview of Station Software with Traceability
SIPLACE Traceability 3.6 SP1 35
6
6 Annex
Annex
6.1
6.1 Overview of Station Software with Traceability
Overview of Station Software with Traceability
Machine types Station software from Line-based and station-
based traceability
Traceability with dual
conveyor
CS/CF 408.xx Line-based traceability
with unforced setup ver
-
ification only
Restricted
S-20, S23, F4, F4-6, F5,
F5HM
407.05 YES Restricted
F5HM 408.xx Line-based traceability
with unforced setup ver
-
ification only
Restricted
S-25 HM, S-27 HM, HS-
50, HS-50+, HS-60, HF,
HF3
505.05 SP2 YES YES
X2, X3, X4
D1, D2, D3, D4
605.03 SP1 YES YES
X2, X3, X4, X4i
DX1, DX2, DX4
SX1, SX2, SX4
705.04 YES YES
X2, X3, X4, X4i
DX1, DX2, DX4
SX1, SX2, SX4
X3 S, X4 S, X4i S
706.xx YES YES
X2, X3, X4, X4i
DX1, DX2, DX4
SX1, SX2, SX4
X2 S, X3 S, X4 S, X4i S
X4 S micron,
X4i S micron
707.xx YES YES
Annex
Supported Hardware
36 SIPLACE Traceability 3.6 SP1
6.2
6.2 Supported Hardware
Supported Hardware
Standards
SIPLACE recommends the observance of the following standards for all line computers (SIPLACE Pro
Server, SIPLACE Pro Client, SIPLACE stand-alone computer configuration).
Obervance of standards
Product safety
Global IEC 60950
Europe EN 60950
USA UL 60950 3rd. Ed.
Canada CAN/CSA-C22.2 No. 60950 3rd ed.
Electromagnetic compatibility
Europe EN 55 022 class B, EN 55024,
EN61000-3-2 /-3
USA / Canada FCC class A
Declaration of conformity
Europe (CE) 89/336/EWG (EMW)
72/213 EEC (LVD)
North America FCC class A
Applicability
Europe EN ISO 9241-11
