Installat ion Manual  W arning / Cauti on !! （ 1 ） Risk of electri cal shock an d energy hazar d. All fa i l u re should be examined by a q ualified technician. Please do not remove the case o f the power supp ly by yo …

Installation Manual

（3）Use copper wire only, and recommended wires are shown as below.

AWG

Rated Current of

Equipment (Amp)

6A 6-10A 13-16A 16-25A

Cross-section of

Lead(mm

)

0.75 1.00 1.5 2.5

Note

：

Current each wire carries should be de-rated to 80% of the current suggested

above when using 5 or more wires connected to the unit.

Make sure that all strands of each stranded wire enter the terminal connection and the screw terminals are

securely fixed to prevent poor contact. If the power supply possesses multi-output terminals, please make

sure each contact is connected to wires to prevent too much current stress on a single contact.

（4）Use wires that can withstand temperatures of at least 80°C such as UL1007.

（5）Recommended wire strapping length is 6.5mm (0.255”).

（6）Recommended screwdriver is 3mm, slotted type.

（7）The recommended torque setting for terminals is 5.8 kgf-cm (5.0 Lb-in).

（8）Suggested fuse and maximum number of the MDR PSUs that can be connected to a circuit breaker at 230V are

shown as below.

Model Fuse

Circuit breaker

C16

D16

MDR-10 T2A/L250V 11 22

MDR-20

T2A/L250V

MDR-40 T2.5A/L250V 6 13

MDR-60 T2.5A/L250V 4 9

MDR-100

T4A/L250V

（9）Mounting Instruction：

Mount as shown in figure only, with input terminals down, or else sufficient cooling will not be possible.

Admissible DIN rail：TS35/7.5 or TS35/15

For rail fastening：

（a）Tilt the unit slightly rearwards.

（b）Fit the unit over top hat rail.

（c）Slide it downward until it hits the stop.

（d）Press against the bottom for locking.

（e）Shake the unit slightly to check the locking action.

（10）For other information about the products, please refer to www.meanwell.com

for details.

"Click"

Installation Manual

 Warning / Caution !!

（1） Risk of electrical shock and energy hazard. All failure should be examined by a qualified technician. Please do

not remove the case of the power supply by yourself!

（2） Risk of electric arcs and electric shock (danger to life). Connecting both the

primary and the secondary sides

together is not allowed.

（3） Risk of burn hazard. Do not touch the unit in operation and shortly after disconnection!

（4） Risk of fire and short circuit. The openings should be protected from foreign objects or dripping liquids.

（5） Only install the unit in a pollution degree 2 environment (Note.1).

（6） Please do not install the unit in places with high moisture or near the water.

（7） The maximum operating temperature is 35°C for MDR-100-12 and 40°C for MDR-100-24, MDR-100-48 and

50°C for MDR-10/20/40/60 series, please do not install the unit in places with high ambient temperature or

near fire source.

（8） The FG ( ) must be connected to PE (Protective Earth).

（9） Output current and output wattage must not exceed the rated values on its specification.

（10）Disconnect system from supply voltage:

Before commencing any installation, maintenance or modification work: Disconnect your system from

supply voltage. Make sure that inadvertent connection in circuit will be impossible!

（11）For continued protection against risk of fire, replace only with same type and rating of fuse.

Pour ne pas compromettre la protection contre les risqué d’incendie, remplacer par un fusible de même

type et de memes caractéristiques nominales.

Note.1: Pollution Degree 2 applies where there is only non-conductive pollution that might temporarily become

conductive due to occasional condensation. Generally refer to dry, well-ventilated locations, such as

control cabinets.

Installation Manual

Manufacturer

：

MEAN WELL ENTERPRISES Co., LTD.

No.28, Wuquan 3rd Rd., Wugu Dist.,

New Taipei City 24891, Taiwan

Tel: +886-2-2299-6100

Web: www.meanwell.com

Branch Office

：

China

MEAN WELL (GUANGZHOU)

ENTERPRISES Co., LTD.

No.11, Jingu South Road, Huadong

Town, Huadu Distric, Guangzhou,

Gungzhou, China

Tel: +86-20-3773-7100

Web: www.meanwell.com.cn

China

SUZHOU MEAN WELL

TECHNOLOGY Co., LTD.

No.269 Changping Rd. , Huangdai

Town, Xiangcheng District

Suzhou, Jiangsu Province, China

Post Code: 215152

Tel: +86-512-6508-8600

Web: www.meanwell.cc

U.S.A.

MEAN WELL USA, INC.

44030 Fremont Blvd., Fremont,

CA 94538, U.S.A.

Tel: +1-510-683-8886

Web: www.meanwellusa.com

Europe

MEAN WELL EUROPE B.V.

Langs de Werf 8, 1185XT Amstelveen, The

Netherlands

Tel: +31-20-758-6000

Web: www.meanwell.eu

2026.01.12
