N7203A022B.pdf - 第20页
2-B T/F ; 8mm ダ ブル ;タ イプA Tape Feeder; 8 mm Double; Ty pe A パーツレイアウト Kit No. キット品 番 Kit N am e キット名称 KXF W 1KSBA00 ｾｸｼｮﾝN o. PARTS LAYOUT Section No. - - M9 ( KKXFW1KSBA00-54-2 )
Ref
No.
Remarks
R
1
Q'ty
2-A
T/F
;
8mm
ダ
ブル
;タ
イプA
Tape Feeder; 8 mm Double; Type A
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFW1KSBA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PRESSER-COVER
2
1 N610092834AC
TENSIONER
1
2 N610025477AB
LEVER
1
4 N610025484AB
LEVER
1
5 N610025485AB
Fulcrum spring
2
6 N610071897AA
COVER
2
7 N210123197AA
MAGNET
2
8 KXF0DYAZA00 NEO33
SCREW
2
9 XXE25C3FP
Hexagon socket set screw Flat point M2.5X3-45H SCHP
COVER
2
10 N210103441AB
SPRING
2
11 N210017141AA
PIN
2
12 N210071635AA
SPRING
2
13 N210114131AA
GEAR
2
14 N210047118AB
PIN
2
15 KXFA1KPAA00
PIN
1
16 KXFA1KQAA00
PIN
1
17 KXFA1KRAA00
COMB
2
18 N210116209AA
SCREW
2
19 XSS3+6VW
Cross recessed Countersunk head machine screw M3X6-A2-70
SCREW
4
20 N510002400AA SUSB Taptite pan head 2.6 8
PIN
1
21 KXFA1KFAA00
ROLLER
2
22 KXFA1KHBA00
SPRING
2
23 KXF0DK4AB00 (DA KXF0DK4AB00)
PIN
1
24 N210045625AA
LEVER
1
25 N210120308AA
LEVER
1
26 N210120309AA
PIN
2
29 N210071634AA
PLATE
2
30 N210124272AA
SCREW
4
31 XSS25+6VW
Cross recessed Countersunk head machine screw M2.5X6-A2-70
M8
--
( KKXFW1KSBA00-54-1 )
2-B
T/F
;
8mm
ダ
ブル
;タ
イプA
Tape Feeder; 8 mm Double; Type A
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
KXFW1KSBA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M9
( KKXFW1KSBA00-54-2 )
Ref
No.
Remarks
R
1
Q'ty
2-B
T/F
;
8mm
ダ
ブル
;タ
イプA
Tape Feeder; 8 mm Double; Type A
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFW1KSBA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
CLICK
1
1KXFW1KWJA00
OPERATING-SW
1
3 N610033140AA
COMB
1
4 N210116210AA
COMB
1
5 N210116211AA
SCREW
4
6 XSN25+3VW
Cross recessed Pan head machine screw M2.5X3-A2-70
GEAR
2
7 N210047118AB
PIN
1
8 KXFA1PS9A00
PIN
1
9 KXFA1L0AA00
PIN
1
10 KXFA1KAAA00
PIN
1
11 KXFA1KBAA00
CLICK
1
12 N210109639AA
CLICK
1
13 N210109640AA
SPRING
2
14 KXF0DRSAA00 (DA 0DRSA)
PLATE
1
15 KXFA1PZHB01
SCREW
2
16 XSN25+4VW
Cross recessed Pan head machine screw M2.5X4-A2-70
RETRACTING-MOTOR
2
21 N510043589AA
GEAR
2
22 N210050452AA
SEAL
1
23 KXF0DWTKA00 (DA KXF0DWTKA00)
SENSOR
2
24 N510037012AA PM-U24-M4
BOLT
4
25 N510017337AA
Hexagon socket head cap screw M3X6-10.9 A2J (Trivalent)
PIN
1
26 KXFA1KLAA00
PIN
1
27 KXFA1KEAA00
SCREW
2
28 N510018959AA
Cross recessed Pan head machine screw M2.5X18-4.8 A2J (Trivalent)
SPACER
2
29 KXF08WXAA00 C-2607
WASHER
4
30 N510018477AA
Small round-plain washer 2 10H A2J (Trivalent)
NUT
2
31 XNG2BVW Hexagon nut Type-2 Best class M2-6H-A2-70
SCREW
2
32 N510002402AA SUS M2x16+TB2430
M10
--
( KKXFW1KSBA00-54-2 )
