Mixer Accessories
2K Products
For medium- and high-pressure systems where pressure inside
the mixer is greater than 10 bar (150 psi), we recommend that
a metal jacket be used over the mixing nozzle. Nordson EFD
offers a range of low-cost, one-piece jackets. Select Robotic
version where repeat positioning is required.
All EFD manifolds and valves have our standard 7/8 - 14 thread.
We also offer several jackets in both standard and an alternative
7/8 - 9 thread for your convenience.
We also offer jackets for the 162A Series which have a 1 5/16-12
thread.
One-Piece Metal Jackets
Part # Material Thread Mixer
Part #
Mixer
7701124 Aluminum, Robotic 2K Standard 7/8 - 14 7700837 Series 160
7701140 Aluminum 2K Standard 7/8 - 14 7700819 Series 160
7701143 Aluminum 2K Standard 7/8 - 14 7700856 Series 160
7701163 Aluminum Alternative 7/8 - 9 7013510 Series 160
7701165 Aluminum, Robotic 2K Standard 7/8 - 14 7700904 Series 160
7701167 Aluminum 2K Standard 7/8 - 14 7700904 Series 160
7701170 Aluminum, Robotic 2K Standard 7/8 - 14 7700927 Series 160
7701171 Aluminum 2K Standard 7/8 - 14 7700927 Series 160
7701174 Aluminum 2K Standard 7/8 - 14 7700932 Series 160
7701203 ACS Nut / SS Jacket 2K Standard 7/8 - 14 7701010,
7701049
Series 160
7701208 Aluminum, Robotic 2K Standard 7/8 - 14 7701010,
7701049
Series 160
7701210 CS Nut / SS Jacket 2K Standard 7/8 - 14 7701028 Series 160
7701226 CS Nut/SS Jacket 1-5/16 - 12 7701059 Series 162A
7701396 Aluminum, Robotic 2K Standard 7/8 - 14 7361695 Series 480
Mixer Applications
• Series 160
• Optimixer Series 480
• Series 162A
2K Products Mixer Accessories
2
2K Products Mixer Accessories
Nordson EFD offers series 100, 160, and 162A mixer nozzles can
be connected to some pre-existing manifolds or valves using
adapters.
Contact Nordson EFD’s Technical Service or Sales Department
for more information on these attachments with regard to your
specic needs.
Mixer Adapters
Mixer Applications
• Series 85
• Series 100
• Series 160
• Series 162A
Nordson EFD’s two-component manifolds separately port
the resin and hardener into the mixing nozzle. Cleanup simply
involves wiping the manifold face after the nozzle has been
removed.
To prevent back ow or cross contamination of reactive material,
in-line check valves are available.
Manifolds
Mixer Applications
• Series 160
• Series 162A
Part # Material Inlet Outlet Solvent Ports Mixer
7701323 Aluminum (2) 1/8" FNPT 7/8 - 14 1/4" FNPT Series 160
7701325 Aluminum (2) 1/4" FNPT 7/8 - 14 1/4" FNPT Series 160
7701329 Aluminum (2) 1/2" FNPT 1-5/16 - 12 UN 1/4" FNPT Series 162A
Luer Lok adapters (locking hubs) are used for attaching Optimum
dispensing tips to Series 190 and 160 mixers. If you want to use
a metal jacket with the 3.16” ID or 1/4” ID bell mixers, order the
mixer and the Luer Lok tting as two separate items unassem-
bled: square hub outlet and #700943 Luer Lok tting (bag of 50).
Dispensing Tips for Mixers
Part # Material Inlet
7701254 Carbon Steel 1/4" Male NPT
3
