Ref No. Remark s R 1 Q'ty 1-A 本 体部 Main Body ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit N o . キット品 番 Kit Name キット名称 N610012842AA Part Nam e 備 考 ｾｸｼｮﾝNo. PARTS LIST Section No. R 3 FRAME 1 1 N210025934AJ BOLT 4 2 KXF…
1-A
本
体部
Main Body
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012842AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M1
( KN610012842AA-35-1 )
Ref
No.
Remarks
R
1
Q'ty
1-A
本
体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610012842AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
FRAME
1
1 N210025934AJ
BOLT
4
2 KXFB05CGA01
PLATE
4
3 N210009258AA
COLLAR
4
4 KXFB05CKA01
BRACKET
1
17 KXFB00JJA01
BRACKET
1
18 N210025981AB
BRACKET
1
20 N210041737AB
COVER
1
26 N210026169AA
BRACKET
1
27 N210041742AB
BRACKET
1
28 KXFB0AQFA00
BRACKET
1
35 N210035671AA
RUBBER-LEG
7
90 KXF01E6AA00 C-30-RK-12
WASHER
3
94 N510021595AA MMSRB4.5-2.0
NUT
4
95 N510017920AA
Hexagon nut Type-3 Best class M30-6H-4T A2J (Trivalent)
WASHER
4
96 N510018511AA
Round finish plain washer 30 10H A2J (Trivalent)
PIN
2
122 KXF0529AA00 SPP3-10
BOLT
7
133 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
2
136 N510017376AA
Hexagon socket head cap screw M4X6-10.9 A2J(Trivalent)
BOLT
2
137 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
15
138 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
2
144 N510017386AA
Hexagon socket head cap screw M5X10-10.9 A2J (Trivalent)
BOLT
22
145 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
6
146 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
4
151 N510017470AA
Hexagon socket head cap screw M8X16-10.9 A2J (Trivalent)
BOLT
4
154 N510017472AA
Hexagon socket head cap screw M8X20-10.9 A2J (Trivalent)
WASHER
12
155 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
2
156 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
2
160 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
3
163 N510020099AA Thick washer for M4
WASHER
28
164 N510020100AA Thick washer for M5
WASHER
4
177 N510020102AA Thick washer for M8
TERMINAL
1
180 N210001551AA
TERMINAL
1
189 N210001551AA
TERMINAL
1
190 N210001550AA
BOLT
96
202 N510017534AA
Hexagon socket button head screw M4X6-10.9 A2J (Trivalent)
BRACKET
1
213 N210069193AA
CAP
4
214 KXF09WEAA00 CP-30-BC-24
M2
--
( KN610012842AA-35-1 )
1-B
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610012842AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M3
( KN610012842AA-35-2 )
