SMT Software Engineering Group IM Operati ons Y AMAHA MOTOR CO., L TD. MDOC-SOFT50 236 1/ 5 Enh anc ed Enh anc ed Enh anc ed Enh anc ed     R eco gni t ion Reco gni tion Reco gni tion Reco gni tion     Im a ge Im…

100%1 / 5
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50236
1/5
Enhanced
EnhancedEnhanced
Enhanced
Recognition
RecognitionRecognition
Recognition
Save
SaveSave
Save
Function
FunctionFunction
Function
Contents
ContentsContents
Contents
EnhancedRecognitionImageSaveFunction
................................................. 1
1.TargetModelandVersion
.................................................................................................... 2
2.Summary
.......................................................................................................................................... 2
3.Setting
............................................................................................................................................... 3
4.Limitations
...................................................................................................................................... 5
Revision No Version Chapter No. Revised Contents
00
V3.41STDR1.000
V4.40R1.011
All New creation
The information contained in this message may be co
nfidential and legally protected under applicable l
aw. The
message is intended solely for the addressee(s).
If you are not the intended recipient, you are here
by notified that anyuse, forwarding, dissemination,
or reproduction
of this message is strictly prohibited and maybe unlawful.
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50236
2/5
1
11
1.TargetModelandVersion
.TargetModelandVersion.TargetModelandVersion
.TargetModelandVersion
Thetargetmodelandversionareasfollows.
Table1.1Targetmodelandversion
TargetModel,Software TargetVersion Remarks
YG300, YS88, YS100,
YS24, YS24X, YS12,
YS12P, YS12F, YG12F,
YC8,
VGOSV3.41STDR1.000andlater
YSM40 VGOSV4.40R1.011andlater
2
22
2.Summary
.Summary.Summary
.Summary
IthasbecomepossibletousetheRecognitionImageSavefunctionwithMulti-cameraandSide
Viewcamera.(ItusedtobeonlywithCo-PlanarityCheckerbefore.)
Accordingtothisissue,the[Co-PlanarityRecognition]iconhasbeenchanged.
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50236
3/5
3
33
3.Setting
.Setting.Setting
.Setting
・Explanationofeachsettingitem.
●MultiCamSaveCondition
MultiCamSaveConditionMultiCamSaveCondition
MultiCamSaveCondition
※①
※①※①
※①
Setting Function
NoSave Visionimageisnotsaved.
ErrorOnly Visionimageissavedonlywhenrecognitionerroroccurs.
AllSave Allvisionimagesaresaved.
OnlyVisionGapError Visionimageissavedonlywhenvisiongaperroroccurs.
●SideViewSaveCondition
SideViewSaveConditionSideViewSaveCondition
SideViewSaveCondition ※②
※②※②
※②
Setting Function
NoSave Visionimageisnotsaved.
AllSave Allvisionimagesaresaved.
MultiCamOK,SideViewNG Vision image is saved only when Multi-camera recognition is
OK,andalsoSideviewrecognitionisNG.
ErrorOnly Vision image is saved only when Side view recognition error
occurs.
※①
※①※①
※①
※②
※②※②
※②
※③
※③※③
※③
※④
※④※④
※④
※⑤
※⑤※⑤
※⑤
