Tape feeder module 4 mm X
Page 9 / 11 18.11.2021
Pos. Item no. Description Part marking
1 03087779-01 TAPE FEEDER MODULE 4MM X
2 00305725-01 DIN 7985-M3 X 5-4.8-H
3 03031194S05 PCB /CONTROL BOARD TAPE-
FEEDER X-SERIES
SPARE PART
4 03052072S01 COVER LEFT SIDE CPL. /FEEDER X8 SPARE PART
5 00315244S01 TRANSPARENT ADHESIVE TAPE,
TYPE 65026
CONSUMABLE
6 03033796-01 REMFORM-SCREW RF-SN75-2,5 X
6-9.8
STANDARD PARTS
7 03033798-01 REMFORM-SCREW RF-SN75-2,5 X
10-9.8
STANDARD PARTS
8 00328542-01 SN 213307-H-M2,5 X 6-A2 STANDARD PARTS
9 03012357S01 LEAF SPRING / TAPE INPUT X 8 SPARE PART
10 03003221S01 AXIS D6, BELLOWS HOLDER X8 SPARE PART
11 03009198S01 HANDLE CPL. / X-SERIES Spare Part
12 03002629-01 CONTROL PANEL COMPLETE /X-
SERIE
13 03002644S01 WINDOW /CONTROL PANEL SPARE PART
14 03021637S01 CONTROL PANEL KEY COVER CPL.
/X-SERIES
SPARE PART
15 03033796-01 REMFORM-SCREW RF-SN75-2,5 X
6-9.8
STANDARD PARTS
16 03008699-02 TAPE CHANNEL X8 SPARE PART
17 03003994S01 SLIDE GUIDE /REAR L200 SPARE PART
18 03003541S02 DISTRIBUTOR BOARD 8/12 X SPARE PART
19 03087786-01 DRIVE WITH MOUNTING PARTS X4
20 03050957-01 SHOULDER BOLT DIA4X3.15 M3 SPARE PART
21 03042524-01 ISO 4762 - M 2 X 5-A2-70 STANDARD PARTS
22 03023217-01 ISO 7046-2-M2 X 5-A2-70-H STANDARD PARTS
23 03022426-01 CABLE FIXING SPARE PART
24 03015691S01 LEVER/ OPENER PICKUP WINDOW
X8-12
SPARE PART
25 03013678S03 PCB/EDIF SECONDARY IRDA BOARD Spare Part
26 03011739S03 ENERGY-DATA INTERFACE CPL. /X-
SERIES
SPARE PART
27 03012683-01 COMPRESSION SPRING D-027 SPARE PART
28 03010185S01 ROTARY SLIDE / COMPONENTS
DISPOSAL X8
SPARE PART
Tape feeder module 4 mm X
Page 10 / 11 18.11.2021
Pos. Item no. Description Part marking
29 03087785-01 DRIVE COMPL. X4
30 03012488-01 SN 213307-H-M2 X 2.5-A2
31 03023216-01 ISO 7046-2-M2 X 4-A2-70-H
32 03087784-01 ENGINEMOUNTING PRE-ASSEMBLED
X4
33 03019604S01 SLIDING FOIL X-FEEDER SPARE PART
34 03058808S01 SLIDING GUIDE SPARE PART
35 00359779-01 DIN 6325 - 3M6 X 10-ST
36 03005196-01 ROLL, LOCKING X-SERIES SPARE PART
37 03023240-01 ISO 7046-2-M3 X 10-A2-70-H STANDARD PARTS
38 00349527-01 ROUND MAGNET 3X4 NEODYMIUM SPARE PART
39 03087341S01 MAGNETIC SHIELD X4 SPARE PART
40 03018028-01 CURVED SPRING WASHER FS3X4,5
41 03023216-01 ISO 7046-2-M2 X 4-A2-70-H
42 03087962-01 FOIL DISPOSAL COMPLETE X4
43 03050686S02 MOTOR CPL. /FOIL DISPOSAL X-
SERIES
SPARE PART
44 03043774-01 ADJUSTMENT WASHER /D3.1 D15
T0,1
STANDARD PARTS
45 03087963-01 STRIPPING SHEET METAL X4
46 03042532-01 ISO 4762 - M 2,5 X 5-A2-70 STANDARD PARTS
47 03012488-01 SN 213307-H-M2 X 2.5-A2
48 03043064-01 TRANSMISSION STEP 1 /FOIL
DISPOSAL X8-88
SPARE PART
49 03042535-01 ISO 4762 - M 2,5 X 10-A2-70 STANDARD PARTS
50 03010342S02 RATCHET BRACE COMPL./ FOLD
ROLLER X8
SPARE PART
51 03009848-01 DIN 1469-C 2 X 6-ST
52 00318387-01 SN 213307-H-M2 X 3-A2
53 03042536-01 ISO 4762 - M 2,5 X 12-A2-70 STANDARD PARTS
54 03023228-01 ISO 7046-2-M2,5 X 6-A2-70-H STANDARD PARTS
55 03062904-02 FOIL ROCKER COMPL. X4
56 03023217-01 ISO 7046-2-M2 X 5-A2-70-H STANDARD PARTS
57 03087787-01 FOIL CASE CPL. X4
58 00619823-01 DIN 6325 - 2M5 X 8-ST
59 00341370S01 BLADE, PARTITION SPARE PART
Tape feeder module 4 mm X
Page 11 / 11 18.11.2021
Pos. Item no. Description Part marking
60 03087914-01 COMPENSATOR COMPL. X4
61 00318387-01 SN 213307-H-M2 X 3-A2
62 03087913S01 STRIPPING SHEET METAL X4 SPARE PART
63 03042321S01 BEARING SHAFT COMPENSATOR /X8 SPARE PART
64 03087915S01 TAMP WHEEL PLANE X4 SPARE PART
65 03042321S01 BEARING SHAFT COMPENSATOR /X8 SPARE PART
66 03088304S01 FLAP FOIL DISPOSAL CPL. X4/E2011 Spare Part
67 03087953-01 FLAP FOIL DISPOSAL X4/E2011
03003124S03 FLAP /FOIL DISPOSAL X8 SPARE PART
69 00349527-01 ROUND MAGNET 3X4 NEODYMIUM SPARE PART
70 03010209-01 ISO 7045 - M2.5 X 6-A2-50-H STANDARD PARTS
71 03088366S01 PICKUP WINDOW X4 SPARE PART
72 03023216-01 ISO 7046-2-M2 X 4-A2-70-H
03032819S01 CABLE /IRDA - EDIF SECONDARY SPARE PART
03006814-01 CABLE SENSOR FOIL ROCKER SPARE PART
03006815-01 CABLE SENSOR REMOVAL HANDLE SPARE PART
03006816-01 CABLE: CONTROL PCB TO
DISTRIBUTOR PCB
SPARE PART
77 03071821-01 SN 213307-H-M2,5 X 3-A2-70 STANDARD PARTS
78 03023217-01 ISO 7046-2-M2 X 5-A2-70-H STANDARD PARTS
