i-pulse i-pulse SDR Sequential Dispensing Robot PARTS LIST LG7-0207#00

100%1 / 21
i-pulse
i-pulse
SDR
Sequential Dispensing Robot
PARTS LIST
LG7-0207#00
i-PULSE Co., Ltd.
1-9-3 Shinmiyakoda, Hamamatsu-city,
Shizuoka-pref., 431-2103 Japan
Tel: (81)53-484-1871 Fax: (81)53-484-1870
All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose,
without the express permission of i-PULSE Co.,Ltd.
Contents
1 Head Section
Head (1/2) 1-1
Head (2/2) 1-2
2 Conveyor Section
Conveyor -1 (1/2) 2-1
Conveyor -1 (2/2) 2-2
Conveyor -2 2-3
3 Base Section
Base 3-1
4 X-axis Section
X-axis 4-1
5 Y-axis Section
Y-axis 5-1
6 Electric Section
Electric 6-1
