3D Automated Optical
Inspection (AOI) Systems
3Di Series
SAKI's 3D AOI Series is designed
for the Smart Factory Connection
E-mail:sakicorp@sakicorp.com
Saki CorporationSaki Corporation
Headquarters
DMG MORI Tokyo Digital Innovation Center
3-1-4, Edagawa, Koto-ku, Tokyo, 135-0051, Japan
TEL: +81-3-6632-7910 FAX: +81-3-6632-7915
Global Network
http://www.sakiglobal.com
3D-AOI
SMT Process
3D-AXI
X-Ray
Inspection Process
2D-AOI
Conformal Coating
Inspection Process
3D-AOI
Selective Soldering
Inspection Process
Internet
3D-AOI
SMT Process
3D-SPI
SMT Process
Cloud-based
Management System
2 3
Saki's Total Smart Factory Inspection Solution
QUALITY DRIVEN Production
SAKI maximizes production efficiency by
improving production-line quality.
Advantages of SAKI's Total Inspection Solutions
Today's technologies and markets demand advanced manufacturing,
high-mix low-volume production, precision quality, short lead times,
and low total cost-of-ownership. Saki's high-speed, high-accuracy
inspection and measurement systems, with enhanced software and
hardware platforms, satisfy those requirements.
Saki's data capture capabilities and machine-to-machine (M2M)
connectivity maximize production efficiency for the Smart Factory.
Saki systems inspect the entire assembly process:
• Screen printing
• Dispensing
• Component placement
• Reflow
• Selective soldering
• Conformal coating
※ SPI: Solder Paste Inspection AOI: Automated Optical Inspection
Improve
production
quality
Improve
production
efficiency
Improve
profits
Benefits provided with Saki’s 3D-AOI series
Productivity
Costs
Profits
4 5
Programming
⁃
One common platform supports 3D-SPI, 3D-AOI, and 3D-AXI
⁃
Saki Self-Programming (SSP) Software
⁃
Compliant with IPC standards
Measurement Inspection & Tuning Function
⁃
Offline-debugging with real-time program adjustments
⁃
Height and extra component detection (ECD) functions
⁃
Through-hole device solder inspection
Verification
⁃
History Management System for data
logging and history
⁃
Golden & Silver Sample Check Function for
process verification
⁃
Side cameras capture areas
missed by overhead cameras
Machine Stability and Accuracy
⁃
Self-diagnostic functions
⁃
Rigid gantry structure and dual motor drive system
⁃
High resolution linear scale for accurate positioning
⁃
CoaXPress camera for faster inspection & measurement process
Flexible Configurations for Diverse Requirements
⁃
Accurate 3D inspection & measurement for entire PCBA
⁃
Scalable optical resolutions of 7µm,
12 µm, and 18 µm
⁃
Flexible gantry for M/L/XL PCBA
sizes and dual lanes
Quality First
QUALITY DRIVEN Production
Saki's 3D-AOI systems
improve process quality,
efficiency, and productivity
to improve profits.
Saki combines proprietary hardware and software to produce a stable,
highly accurate system that improves production and maximizes
process efficiency and product quality.
AOISPI
Key Factor 1
Advanced Hardware Features
Key Factor 2
Advanced Software Features
Key Factor 3
Applied Technology
Machine-to-Machine Systems
⁃
Feed-back from SPI to printer
⁃
Feed-forward from SPI to Pick-and-Place
⁃
Feed-back from AOI to Pick-and-Place
Stand-alone Systems
⁃
RMS remotely manages multiple BF2-Monitors with one PC
⁃
MPV lets operators see every inspection result in real time
AOISPI AOISPI
