NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK 1 J44010031B PC󰚟POWER󰚟SUPPLY 1 2 J4804002A 485󰚟COMMUNICATION󰚟CARD 1 3 J4809045A BACK󰚟PLAN󰚟BOARD 1 PCI/18SD 4 J48090046B CPU󰚟BOARD 2 F815D/V󰚟REV󰚟2.0 5 J4901014A CPU …

100%1 / 111
11
12
10
15
13
15
3
1
8
9
6
5
4
14
7
2
4
S AMS UNG TE CHWIN
NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK
1 J44010031B PC󰚟POWER󰚟SUPPLY 1
2 J4804002A 485󰚟COMMUNICATION󰚟CARD 1
3 J4809045A BACK󰚟PLAN󰚟BOARD 1 PCI/18SD
4 J48090046B CPU󰚟BOARD 2 F815D/V󰚟REV󰚟2.0
5 J4901014A CPU 2 INTEL󰚟CELERON󰚟1.2GHz
6 J5001009A MODULE󰚟RAM 1 168PIN󰚟128M󰚟(PC133)
7 J51010028B FLASH󰚟DISK 1 MD1150-D32󰚟Rev󰚟1.11
8 J5101026A HARD󰚟DISK󰚟DRIVE 1
9 J6102018A CABLE󰚟CHAIN 1
10 J9060117A PCB󰚟ASS'Y 1 CP60-ISA_DPRAM_MASTER󰚟BOARD󰚟ASS'Y
11 J9060118A PCB󰚟ASS'Y 1 CP60-ISA_DPRAM_SLAVE󰚟BOARD󰚟ASS'Y
12 J9060126B PCB󰚟ASS'Y 1 CP60-CAN_MASTER󰚟BOARD󰚟ASS'Y
13 J9060236A MONO󰚟CAMERA󰚟BOARD 1
14 J9060376A PCB󰚟ASS'Y 1
15 J9060319B CSPCI-5 2 FRAME󰚟GRABBER󰚟BOARD
16
17
18
19
20
21
22
23
24
25
26
27
S AMS UNG TE CHWIN
R
E
A
R
4
5
1
2
3
4
3
5
5
5
