KMS-1904_YST15_MaintePartsList.pdf - 第5页
1 1 Priority 1 Priority No. Part No. Part Name QTY. for 1unit Description Rank Level Rev. 1 1 1 1 1 1 3 3 4 5 6 2 2 KMS-M8611-00 KMS-M8612-00 KMS-M8613-00 KMS-M8614-00 KMS-M8615-00 KMS-M8616-00 G2105 BOARD ASSY G2103 BOA…
Contents
1 Priority
Priority 1 1-1
Priority 2
.........................................................
.........................................................
.........................................................
.........................................................
1-3
Priority 3 1-5
2
Others
Others 2-1
1
1
Priority 1
Priority
No. Part No. Part Name QTY. for 1unitDescription Rank LevelRev.
1
1
1
1
1
1
3
3
4
5
6
2
2
KMS-M8611-00
KMS-M8612-00
KMS-M8613-00
KMS-M8614-00
KMS-M8615-00
KMS-M8616-00
G2105 BOARD ASSY
G2103 BOARD ASSY
ENCODER ASSY
Y MOTOR ASSY
X MOTOR ASSY
RUNNER GI 32
G2105 Board for Zero Sensor of each axis.
Handler Board G2103
Encorder EL38F for Axis Y and Axis X
Y Motor Assy
X Motor Assy
Runner GI32 for Y Counterweight
5
1
2
1
1
2
B
B
B
B
B
A
○
△
×
×
×
△
1
2
3
4
5
6
1
2
Priority 1
Priority
No. Part No. Part Name QTY. for 1unitDescription Rank LevelRev.
1
1
1
2
2
2
3
3
KMS-M8617-00
KMS-M8618-00
KMS-M8619-00
MOTOR ASSY
SENSOR,NPN IFN
SENSOR,PNP OPE.ZONE
Motor Assy for Forward/Open/Rotation
Photocell sensor for Reel detection
Photocell sensor for Reel detection on
loading/unloading area
3
3
2
1
2
3
B
B
B
×
△
△
