1 5 Priority 3 Priority No. Part No. Part Name QTY. for 1unit Description Rank Level Rev. KMS-M8631-00 KMS-M8632-00 KMS-M8633-00 KMS-M8634-00 KMS-M8635-00 KMS-M8636-00 BELT,WHITE Y-AXIS BELT,BLACK X-AXIS BELT,Y-AXIS MOTO…
1
4
Priority 2
Priority
No. Part No. Part Name QTY. for 1unitDescription Rank LevelRev.
1
KMS-M8627-00
KMS-M8628-00
KMS-M8629-00
KMS-M862A-00
KMS-M862B-00
KMS-M862C-00
HNS,MAINBOARD
HNS,POWER HANDLER
HNS,KONTEK HANDLER
HNS,ROT.HANDLER OR
HNS,ROT.HANDLER GR
MULTI CODE READER
Canbus cable between Mainboard to Handler
Power cable for Handler
KONTEK cable for Open/Close axis on handler
Orange Cable for Rotation axis on handler, Power
Gray Cable for Rotation axis on handler, Signal
Barcode Reader DS4800 in Cabinet
1
1
1
1
1
1
1
6
2
44
3
5
5
1
2
3
4
5
6
B
B
B
B
B
B
×
×
△
△
△
×
1
5
Priority 3
Priority
No. Part No. Part Name QTY. for 1unitDescription Rank LevelRev.
KMS-M8631-00
KMS-M8632-00
KMS-M8633-00
KMS-M8634-00
KMS-M8635-00
KMS-M8636-00
BELT,WHITE Y-AXIS
BELT,BLACK X-AXIS
BELT,Y-AXIS MOTOR
CONCENTRIC WHEEL
ECCENTRIC WHEEL
BELT,640MXL025
White belt for Y axis
Black belt for X axis
Belt for Y motor
Concentric wheel for Y and X axis
Eccentrtic wheel for Y and X axis
Belt for Forward/Backward axis
2
1
1
6
6
1
1
5
4
4
5
2 3
6
5 4
1
2
3
4
5
6
E
E
E
E
E
E
×
×
×
×
×
×
1
6
Priority 3
Priority
No. Part No. Part Name QTY. for 1unitDescription Rank LevelRev.
KMS-M8637-00
KMS-M8638-00
KMS-M8639-00
KMS-M863A-00
KMS-M6501-00
KMS-M863C-00
BEARING,608ZZ
RUNNER MR12
SUPPORT NUT
WORM SCREW
2D CODE LEADER
HNS,SENSOR
Bearing for Rotaion axis
Runner for Forward/backward & Open/Close axis
Support nut for Open/Close axis
Screw for Open/Close axis
2D Barcode Reader
Cable between photocell sensor and boards.
6
3
1
1
1
5
1
1
3
5
4
2
2
6
1
2
3
4
5
6
E
E
E
E
A
A
×
×
△
×
×
×
