– 80 – 12,16mm GD GD Joint Detection Unit DS-12162 1 Joint Detection Unit 1710-006 17 17 13 1 1 16 15 12 14 18 3 4 19 5

100%1 / 170
– 79 –
Tape Feeder GT-12162
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
487 KYD-MC20D-00 0926C31G LEVER(SUP) 1
488 KYD-MC22E-00 216F0913 PIN_GUIDE(SUP) 1
489 KYD-MC22K-00 222P0201 SPRING_TORSION 1
493 KYD-MC219-00 212B2299 CHUTE 1
494 KYD-MC21P-00 0926231A ASSY_PLATE(SUP) 1
495 KYD-MC22G-00 221D0196 MACHINE_SCREW 2 PAN M2L1.5
497 90990-02J035 221C0027 SET SCREW 1
498 KYD-MC205-00 0804000L NAME PLATE 1
499 KYD-MC22H-00 221H0230 WASHER 1
4A0 90167-02JA06 221DA103 MACHINE SCREW 1 FLT M2.5L6
4A3 KYD-MC20U-00 09262301 ASSY_SPRING 1
4A4 90990-08J035 221DB001 MACHINE SCREW 1 PAN M2L4
4A5 90167-02JA06 221DA103 MACHINE SCREW 3 FLT M2.5L6
4A6 90166-02JA06 221DA005 MACHINE SCREW 2 PAN M2.5L6
1710-006
– 80 –
12,16mm
GD
GD Joint Detection Unit DS-12162
1 Joint Detection Unit
1710-006
17
17
13
11
16
15
12
14
18
3
4
19
5
– 81 –
Joint Detection Unit DS-12162
1710-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
3 KYD-MC208-00 0926000N ASSY_NAMEPLATE 1
4 KYD-MC209-00 0926000P ASSY_NAMEPLATE 1
5 90990-01J150 221A0098 BOLT_HEX-SCT 2 M4L20 SW+FW
11 KYD-MC232-00 210B4392 FRAME 1
12 KYD-MC235-00 011A0007 ASSY_COVER 1
13 KYD-MC237-00 211A9111 COVER(D) 1
14 KYD-MC238-00 211D9941 PLATE 1
15 KYD-MC140-00 23G10090 SENSOR_PHOTO 1
16 90166-12J206 221DA065 MACHINE_SCREW 2 PAN M2L6 SW+FWS
17 90167-02JA06 221DA103 MACHINE SCREW 4 FLT M2.5L6
18 KYD-MC236-00 0926J003 MACHINE_SCREW 2
19 KYD-MC234-00 212A2467 GUIDE 1
D Ver の場合は下記 Part No. となります。
No.3 : KYD-MC208-10
No.4 : KYD-MC209-10
In the case of D Ver, it becomes the following part number.
No.3 : KYD-MC208-10
No.4 : KYD-MC209-10
