3 Consult our wide range of cartridges with more than 250 r eferences in www .jbctools.com. For Special Cartridges contact with our distributor . C420 Cartridge Range Chip Components Dual in line QFP y PLCC Blade T ype C…
Cartridge Electric
Connection Screw
2
WARNING: It is esential to tighten this screw for
the tool to function.
Important: It is esential to insert the cartridge
till the end for a good connection.
Take the mark as reference and check that
both tips of the tweezer coincide.
Packing list
Changing Cartridges
Features
Thermal Tweezers ..................................... 1 unit
Ref. HT420-A
Manual ........................................................... 1 unit
Thermal Tweezers
Ref. HT420-A
The following items should be included:
Control Unit
Ref. DI, DDE, DME
Stand
Ref. HT-SE
Thermal Tweezers
Ref. HT420-A
C420 Cartridges
(required but not supplied)
Stand Cable
Ref. 0 011283
Use a flat pliers in the indicated area for a
correct tip alignment.
Do not over-tighten the cartridge.
Alignment
Suitable area
for a correct
flat pliers
contact.
PLR195
Cartridge extractor
www.jbctools.com
INSTRUCTION MANUAL
3
Consult our wide range of cartridges with more than 250 references in www.jbctools.com.
For Special Cartridges contact with our distributor.
C420 Cartridge Range
Chip Components
Dual in line
QFP y PLCC Blade Type
Cable stripper
12
15,6
14,3
2
Special Cartridges Special Cartridges
A
A
A
A
A
C420-282C420-281
C420-271 A = 1,5 mm
C420-272 A = 2,6 mm
C420-273 A = 4 mm
C420-274 A = 6 mm
C420-275 A = 8 mm
C420-276 A = 10 mm
C420-277 A = 15 mm
C420-278 A = 20 mm
C420-285 A = 22 mm
C420-279 A = 8 mm
C420-280 A = 11 mm
C420-283 A = 50 mm
C420-281 C420-282
A = 12 mm
B = 15,6 mm
C = 14,3 mm
2 mm
www.jbctools.com
0008868/0418
Specifications
- Net Weight: 110 gr (0.24lb)
- Dimensions: 98 x 36 x 21.5 mm (3.85x 1.41 x 8.46 in)
- Cable Lenght: 1.3 m
- Package Weight: 175 gr (0.39 lb)
- Package dimensions: 277 x 73 x 50 (10.91 x 2.87 x 1.97 in)
Complies with CE standards.
ESD safe.
This product should not be thrown in the garbage.
In accordance with the European directive 2002/96/EC, electronic equipment at the end of their life
must be collected and returned to an authorized recycling facility.
Manual in other languages available on our website
Warranty
JBC’s 2 year warranty covers this equipment
against all manufacturing defects, including the
replacement of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment
must be returned, postage paid, to the dealer
where it was purchased.
Please register your product warranty
within 30 days of purchase in:
www.jbctools.com/productregistration.
