ASM OIS/SIS Databases 14.1 (R17-1) / Interface Description 06/2017 Edition
18
NOTICE
Error types 2-5 are sent from stations with station software as of version 605.
Error types 11-16 are sent from stations with station software as of version 701.
The track number may contain the value -1. This indicates that the track is unknown and
it typically occurs if a MTC is used as feeder.
Definition of lGantry and ucHead
With introduction of the lGantry column, the semantic of the ucHead column has changed. The
content of ucHead column has moved into the lGantry column.
The ucHead now relates to the head position where the head is mounted on the gantry.
I.e., a gantry may carry one or two heads. For gantries with only one head, the head value is
always "1". For gantries, which are able to carry two heads, the following definition of ucHead is
used:
Definition of ucHead values
1: head is located on the right position of the gantry
2: head is located on the left position of the gantry
