Reow soldering by condensation

Multi-faceted processes with the Condenso

The reow soldering eld of industry is wide-ranging, whether it’s in aerospace engineering,

LED manufacture or power electronics. Electronic components only work in end devices

by soldering electronic contacts in a high-quality fashion. But what happens when compo-

nents on the circuit board are very large or high-mass? Or if vacuum soldering processes

should be implemented inline?

In condensation reflow soldering, or vapour-phase soldering, soldering is accomplished

using a hot vapour. To put it in simpler terms: Imagine you have just come from the ski slo-

pe and walk into a warm chalet with cold ski goggles. The goggles fog up instantly. This is

called lm condensation. You can only see clearly again once the ski goggles have reached

room temperature. Condensation soldering works based on the same principle.

In this case, heat transfer in condensation soldering is up to ten times higher than with con-

vection soldering. This means that even large, high-mass boards can be reliably processed in

a stable atmosphere and with innovative vacuum technology with Rehm’s Condenso series.

Condensation

Soldering

Reliable and flexible!

Condenso series | Overview

The Condenso series at a glance

Flexible and adjustable

Do you process large and heavy boards for which condensation soldering is out of the question? Or do you

want a system that you can reliably carry out vacuum processes with at any time? Then choose a Condenso-

Series system that can be customised to your manufacturing environment!

CondensoXC

Space-saving and powerful

› Batch system for low throughput

› Used in laboratory applications, small production

lines or prototyping

CondensoXM smart

All-rounder for electronics production

› Inline system for medium throughput

› Autom. side Loeading/unloading with pre-

assembled carriers

› Used for small and medium-sized series

Condenso smartline

Ideal for large series

› Inline connection for medium throughput

›

Automatical loading, internal carrier return

transport

› Used in series production

CondensoXS smart

Great performance with a small footprint

› Inline ready system for medium throughput

› Low space requirements

› Ideal for small-series production

CondensoX-Line

Reliable in the through-feed process

›

Inline system for high throughput

› 3-chamber system and built-in vacuum soldering

› Series manufacture and power electronics

The Condenso series system versions can be integrated into a wide range of

manufacturing environments. Whether it’s a batch operation, inline connection

or continuous soldering – Rehm offers the highest degree of process reliability

for all areas!

The application options for the Condenso series are as varied as their production.

We would be happy to determine the most efcient system for your manufac-

turing process, taking all relevant processes such as throughput, assembly size,

thermal mass and follow-up processes into account.

›

Patented injection principle – reproducible reow prole

›

Hermetically sealed process chamber

›

Controllable vacuum process – Pre-vacuuming und vacuum feasible after soldering

›

No Galden

spreading, active Galden

ltering

›

Process monitoring with a wireless WPS system (not with CondensoXC)

Vapour phase soldering

in every manufacturing environment
