LG9-0301 Conveyor-1 1 1 Conveyor Part No. Part Name Q'ty Remarks N o . Part No. Part Name Q'ty Remarks 1 LG9-M9001-04X PLATE,FC 1 39 LG9-M9012-01X STAY,FOOT (1) 1 2 LG9-M9002-01X PLATE,FL 1 40 KH2-M9121-00X BEA…

100%1 / 16
LG9-0301
37
34
4038
3
7
23
51
20
21
35
18
19
52
28
35
26
42
31
42
45
11
15
45
13
6
42
40
24
25
7
53
50
50
54
29
32
1
44
12
5
8
32
14
30
4
15
22
41
31
16
31
42
42
26
33
27
17
36
36
17
33
27
55
47
48
49
49
56
57
56
56
56
46
18
19
31
39
9
2
42
10
19
18
19
18
43
14
Conveyor-1
1
1
Conveyor
LG9-0301
Conveyor-1
1
1
Conveyor
Part No. Part Name Q'ty Remarks No. Part No. Part Name Q'ty Remarks
1 LG9-M9001-04X PLATE,FC 1 39 LG9-M9012-01X STAY,FOOT (1) 1
2 LG9-M9002-01X PLATE,FL 1 40 KH2-M9121-00X BEARING 2
3 LG9-M9003-02X PLATE,FR 1 41 KG2-M9108-11X COLLAR,CONVEYOR 1
4 LG9-M9004-01X PLATE,RC 1 42 KV7-M9140-A0X PULLEY,CONV. ASSY 8
5 LG9-M9005-01X PLATE,RL 1 43 LG0-M900A-00X BLOCK,GUIDE(A) 1
6 LG9-M9006-02X PLATE,RR 1 44 LG0-M900B-00X BLOCK,GUIDE(B) 1
7 LG9-M9015-00X JOINT,L 2 45 LG0-M900C-00X BLOCK,GUIDE(C) 2
8 LG9-M9019-00X JOINT,L (2) 1 46 LG0-M90AJ-00X MANIFOLD 1
9 LG7-M9008-00X JOINT,R 1 47 LG0-M90AK-00X MUFFLER 2
10 LG9-M9007-00X PLATE,SPACER FL 1 48 LG0-M90AM-00X JOINT 1
11 LG9-M9008-00X PLATE,SPACER FR 1 49 LG0-M90AP-00X PLUG 3
12 LG9-M9009-00X PLATE,SPACER RL 1 50 LG0-M90H3-00X PHOTO SENSOR 2
13 LG9-M900A-00X PLATE,SPACER RR 1 51 LG0-M90H5-00X DC MOTOR 1
14 LG9-M900B-01X PLATE,GUIDE L 2 52 LG9-M90H1-00X SENSOR,AIRVAL,PCB 1
15 LG9-M900C-00X PLATE,GUIDE R 2 53 LG0-M901B-00X BRACKET (L) 1
16 LG9-M900D-02X PLATE,SUPPORT 1 54 LG0-M901C-00X BRACKET (R) 1
17 LG7-M900E-00X PLATE,SLIDE 2 55 LG0-M90AL-00X SOLENOID 1
18 LG9-M900F-01X STAY,BELT 4 56 LG0-M90AN-00X JOINT 2
19 LG9-M900G-01X SPACER,STAY R 4 57
20 LG9-M900H-00X SHAFT,DRIVE 1 58
21 LG9-M900J-00X PULLEY,DRIVE F 1 59
22 LG9-M900K-00X PULLEY,DRIVE R 1 60
23 LG9-M900L-00X BRKT.MOTOR 1 61
24 LG9-M900M-00X SUPPORT,BRG. 1 62
25 LG9-M900N-00X PLATE,PULLEY 1 63
26 LG9-M900P-00X BRKT.WIDTH R 2 64
27 LG7-M900R-00X BLOCK,NUT 2 65
28 LG9-M900S-00X BRKT.SENSOR 1 66
29 LG9-M900U-01X GUIDE,SIDE(F) 1 67
30 LG7-M900V-00X GUIDE,SIDE(R) 1 68
31 LG9-M900X-00X COLLAR,STAY 8 69
32 LG7-M900Y-00X PLATE,UPPER 15 70
33 LG9-M90A0-00X LINEAR GUIDE 2 71
34 LG9-M90A1-00X COUPRING 1 72
35 LG9-M90A2-00X BELT 2 73
36 LG0-M8887-00X BOLT,WING 2 74
37 99080-06600 CIRCLIP 1 75
38 KV7-M9101-02X STAY,FOOT 1 76
LG9-0301
11
3
8
4
10
6
7
9
5
20
5
1
2
18
17
13
15
28
30
29
38
37
36
34
26
35
20
27
32
31
33
16
18
17
13
12
15
22
22
14
14
16
17
25
15
14
21
23
19
24
24
18
18
Conveyor-2
1
2
Conveyor
