MEMO
22
EG-S001-02
1004-003
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
C-1
1 6301471891 PLATE,LOCATE 3 846C--010-001 216H0458
2 6301482620 BLOCK 1 0 846C--010-002 211G4711
3 6301482538 BLOCK 1 0 846C--010-003 211G4706
4 6301433660 PLUNGER 4 0 846C--010-004 226G0057
5 6301482552 BLOCK 1 846C--010-005 211G4707
6 6301488967 BLOCK 1 846C--010-006 211G4756
7 6301482613 BLOCK 1 846C--010-007 211G4710
8 6301472263 NOZZLE 1 846C--010-008 216M2532
9 6301482606 BLOCK 1 846C--010-009 211G4709
10 6301491790 ASSY,HOLDER 1 846C--010-010 016B0092
11 6301616803 GUIDE,LINEAR 2
846C-A010020-A001
222L0901
12 6301616971 GUIDE,LINEAR 2
846C-A010020-A002
222L0902
13 6301617848 BOLT 4
846C-A010020-A003
221E0443
14 6301566559 BOLT 1
846C-A010020-A004
221E0420
15 6301616032 CLAMP 1
846C-A010020-A005
226H0082
16 6301545318 MECH PARTS(STOPPER) 4
846C-A010020-A006
226J2346
17 6301617763 PLATE 1
846C-A010020-A007
211DD452
18 6301617770 PLATE 1
846C-A010020-A008
211DD453
19 6301605821 PLATE 1
846C-A010020-A009
211DD304
20 6301564739 PLATE 1
846C-A010020-A010
211DC833
21 6301585888 HOLDER 1
846C-A010020-A011
216B1732
22 6301606415 BRACKET 3
846C-A010020-A012
211FC962
23 6301605999 BRACKET 1
846C-A010020-A013
211FC949
24 6301617756 BRACKET 1
846C-A010020-A014
211FD098
25 6301605937 BLOCK 1
846C-A010020-A015
211G5545
26 6301605944 BLOCK 1
846C-A010020-A016
211G5546
27 6301605623 BLOCK 1
846C-A010020-A017
211G5542
28 6301606019 BRACKET 2
846C-A010020-A018
211FC951
34 6300007664 BOLT,HEX-SCT 3 0 846C--010-034 221A0021
37 6300008913 SET SCREW 4 846C--010-037 221C0004
38 4111410505 NUT HEX 5 4 0 846C--010-038 221F0085
39 4111412905 WASHER SPR 4 3 0 846C--010-039 221H0284
40 4111414008 WASHER V 4X9X0.8 3 0 846C--010-040 221H0284
49 6300007497 BOLT,HEX-SCT 16
846C-A010020-A019
221A0004
50 6300007510 BOLT,HEX-SCT 12
846C-A010020-A020
221A0006
51 6300007527 BOLT,HEX-SCT 4
846C-A010020-A021
221A0007
52 6300007602 BOLT,HEX-SCT 6
846C-A010020-A022
221A0015
53 6300007626 BOLT,HEX-SCT 12
846C-A010020-A023
221A0017
54 6300007657 BOLT,HEX-SCT 3
846C-A010020-A024
221A0020
55 6300007688 BOLT,HEX-SCT 4
846C-A010020-A025
221A0023
56 4111131400 SCR PAN 4X6 4
846C-A010020-A026
221E0509
57 4111412806 WASHER SPR 3 4
846C-A010020-A027
221H0281
58 4111412905 WASHER SPR 4 16
846C-A010020-A028
221H0284
59 4111413902 WASHER V 3X7X0.5 4
846C-A010020-A029
221H0312
60 4111415906 WASHER F 4X8X0.8 8
846C-A010020-A030
221H0340
EG -100
EG -S001-01
MEMO
EG-S001-02
0909-002
24
61
51
52
分割認識テーブル ( オプション )
Divided Recognition Table(Option)
EG-S001-02 EG-S001-02
Fig. S-1
標準付属品
- 標準付属品
Standard Accessories-Standard Accessories
