CUBUS FeM - May 2017
Page 4 of 6
Specifications
Reel Specifications
A
Nominal diameter [mm]
F
Distance between two codes [mm]
B
Reel width [mm]
G
Barcode height [mm]
C
Reel bending downwards [mm]
H
Barcode label width [mm]
D
Barcode label area [mm]
J
Barcode label twist [°]
E
Barcode label area [mm]
K*
Reel bending upwards [mm]
Reel Dimensions / Shelf Pitch for 180 mm (7 inches) Reels
Tape width
[mm]
A min [mm]
A max [mm]
B min [mm]
B max [mm]
Recomm.
Shelf Pitch
<1000 g
Recomm.
Shelf Pitch
>1000 g
Recomm.
Shelf Pitch
>2000 g
8
100
178
10.5
14.4
25
30
35
12
18.4
30
35
40
16
22.4
35
40
45
24
30.4
45
45
55
32
38.4
50
50
65
44
50.4
65
65
75
56
62.4
75
75
85
C max [mm] <1000 g
C max [mm] >1000 g
C max [mm] >2000 g
Max Reel weight [g]
2
3
4
3500
K max [mm] <1000 g
K max [mm] >1000 g
K max [mm] >2000 g
Max Reel weight [g]
1
1
1
3500
K* The bending upwards is usually included in the height measurement of the reel. But the bending might be
different between the front or back side of the reel, in this case K must not be higher than the mentioned value.
CUBUS FeM - May 2017
Page 5 of 6
Specifications
Reel Dimensions / Shelf Pitch for 330/380 mm (13/15 inches) Reels
Tape width
[mm]
A min [mm]
A max [mm]
B min [mm]
B max [mm]
Recomm.
Shelf Pitch
<1000 g
Recomm.
Shelf Pitch
>1000 g
Recomm.
Shelf Pitch
>2000 g
8
-
381
10.5
14.4
30
35
35
12
18.4
35
40
40
16
29
45
50
50
24
37
55
55
55
32
45
65
65
65
44
57
75
75
75
56
69
85
90
90
72
89
105
110
110
C max [mm] <1000 g
C max [mm] >1000 g
C max [mm] >2000 g
Max Reel weight [g]
6
7
8
3500
K max [mm] <1000 g
K max [mm] >1000 g
K max [mm] >2000 g
Max Reel weight [g]
3
3
3
3500
K* The bending upwards is usually included in the height measurement of the reel. But the bending might be
different between the front or back side of the reel, in this case K must not be higher than the mentioned value.
CUBUS FeM - May 2017
Page 6 of 6
Specifications
Barcode Label Dimensions
A
Nominal diameter [mm]
F
Distance between two codes [mm]
B
Reel width [mm]
G
Barcode height [mm]
C
Reel bending [mm]
H
Barcode label width [mm]
D
Barcode label area [mm]
J
Barcode label twist [°]
E
Barcode label area [mm]
Barcode Label Dimensions
Type
D max
E min
F min
G min
G max
H max
H min
J max
Max.
number
of labels
Min. size
of
square /
line
1D
110
30
8
8
100
100
8
35°
depends
on G
4
0.3 mm
2D
110
30
8
6
22
22
6
Must be
placed
0° / 90°
180° /
270°
4
0.5 mm
Note:
The system can recognize a maximum of 4 barcode labels.
Barcode Label Recommendation
White and matt labels are recommended.
Other colors or gloss surfaces can impact negatively to the function of the barcode reader or can cause malfunction.
For a proper recognition of the barcode, stick it only on a plane surface. Embossed surfaces, recesses, bumps and
indentations are not suitable.
Within the readable field (D) barcodes side by side (same height) can cause malfunction.
Please ask for the System Description or Product Note for further details of available options
