Easy operation
Ease-of-operation improved by
automatic component measurement
Component data can be programmed simply by
typing approximate dimensions, type and packag-
ing information. Accurate dimensions, number of
leads and lead pitch are measured and
programmed automatically by the machine.
This function assists operators in the preparation of
a new production. By simply following a checklist of
setup items from “1. Automatic width adjustment” to
“8. Production program check,” an operator can be
sure they have performed the necessary steps and
see which have not been completed.
Non-stop Operation
Non-stop operation allows the operator to replace
feeders while the machine continues to run at full
speed.
160 component inputs
Up to 160 different components can be installed on
the machine for ultimate flexibility. The feeder
trolley has no cables or hoses to connect for
ultra-fast, ultra accurate change-overs.
Simple setting of feeder pitch
No tools are required to
change the feeder pitch.
Pitch is set using buttons
on the feeder.
High precision and quality placement
with Electronic feeders
Flexible vision teaching
Complicated programming of odd-shaped compo-
nents is made easier by following step-by-step
guidelines, reducing programming time significantly.
Automatic correction of pick position
※
The position error information of a nozzle is transmit-
ted to each electric feeder so that each electric
feeder automatically adjusts feeding for more stable
pick position and for better simultaneous picks.
Automation Nozzle Changer (ATC)
Automatically replace nozzles according to
component dimensions.
Auto teaching of pick position reduces changeover
time and mis-picks.
Auto Teaching of Pick Position
Centering errors prevented
by self check
Laser contamination is checked prior to the produc-
tion. If contamination is detected, an alarm is given
to prevent centering errors.
High-speed, on-the-fly vision centering
dual upward looking strobing cameras capture images in high speed for large, fine pitch, or odd-form compo-
nents.
【existing recognition】
pause for each component recognition
nozzle
camera
【non-stop Vision recognition】
non-stop recognition for each component
component
Simultaneous on-the-fly component
2 centering for high-speed production
Feeder Position Indicator
Feeder Position Indicator
LED's on the feeder bank indicates which feeder
needs to be replaced or which feeder has an alarm,
indicates location of feeders to be set during change
over, and helps simplify feeder setup.
High-resolution Camera
Enable high-accurate
inspection for components
like QFP with lead pitch 0.2
mm.
Tape Cutter
※
Automatically cuts used tape and stores it in an
easily removable trash bin, eliminating mess and
decreasing operator workload.
Rear-side Operation Unit
Allows complete machine operation from the rear
Adjustment side of the machine.
※Only available on electrical feeder
2.High Productivity
ATC unit(Auto-Tool Changer）
VCS unit
(Vision Centering System)
Trolley set up image
EF08HDRSingle & double lane feeder
Component data is updated
after automatic measurement.
check list
Flexible vision teaching
Laser contamination check
※Option for mechanical feeder specification, standard for electrical feeder specifica-
tion.
Laser sensor is integrated into the placement head
for on-the-fly centering. Head moves directly from
the pick position to the placement position for the
shortest possible head travel and maximum place-
ment speed.
Head moves directly
from the pick to the
placement position
Laser sensor integrated
into placement head
Component
dimensions:
Width
Depth
Height
