JN1DS_817898.pdf - 第14页
MB-0054-8 14/22 JAE PMK Div. Proprietary. Cop yright © 2009, Japan Aviation Electronic s Industry, Ltd. Receptacle JN1AS10ML1-R Connection Side Side View Mating Side Receptacle JN1AS10ML2-R Connection Side Side View …
MB-0054-8
13/22
JAE PMK Div. Proprietary. Copyright © 2009, Japan Aviation Electronics Industry, Ltd.
Receptacle JN1AS04MK1*
Connection Side
Mating Side
Side View
MB-0054-8
14/22
JAE PMK Div. Proprietary. Copyright © 2009, Japan Aviation Electronics Industry, Ltd.
Receptacle JN1AS10ML1-R
Connection Side Side View
Mating Side
Receptacle JN1AS10ML2-R
Connection Side
Side View
Side View (cross section)
MB-0054-8
15/22
JAE PMK Div. Proprietary. Copyright © 2009, Japan Aviation Electronics Industry, Ltd.
Receptacle JN1AS10UL1
Individual Plug JN1ES10SL1
Connection Side
Side View
Mating Side
Side View
Mating Side
Drawing (when mated)
