remote contr ol R ealize remote operation thr ough T CP/IP network , view , star t or stop machine operation, modif y programs and other operations anytime and anywhere Ser ver mode Using a central ser ver , several A OI…
Resolution
Visual Range
Speed
Standard configuration:
15μm/Pixel FOV: 36mmx30mm Detection speed <
200ms/FOV
option:
20μm/Pixel FOV: 48mmx40mm Detection speed <
200ms/FOV
option:
25μm/Pixel FOV: 60mmx50mm Detection speed <
200ms/FOV
option:
10μm/ Pixel FOV: 24mmx20mm detection speed <
200ms/FOV
Standard configuration:
15μm/Pixel FOV: 60mmx45mm Detection speed <200ms/F
OV
option:
10μm/Pixel FOV: 40mmx30mm Detection speed <200ms/F
OV
option:
7μm/Pixel FOV: 28mmx21mm Detection speed <200ms/F
OV
option:
3.45μm /Pixel FOV: 13.80mmx10.35mm detection speed <
200ms/FOV
light source High-brightness RRGB coaxial ring-shaped tower LED light source (color light)
Conveyor system
Bottom-up fixing, automatic compensation for PCB/FPC bending deformation, automatic in and out of boards,
automatic width adjustment of flat belts
Conveyor height
above ground
890 to 980 mm
Conveyor flow
direction
Can be set left to right or right to left
platform marble platform
X/Y platform driver Screw and AC servo motor drive, PCB/FPC fixed, Camera moves in XY direction
power supply AC220V 50/60Hz less than 1.5KVA
air pressure 0.4-0.8Mpa
Operating
environment
temperature and
humidity
10-35℃ 35-80% RH (no condensation)
Functional part
Test content
Component detection: missing parts, reversal, offset, component bent legs, wrong parts, tin stain, glue overflow,
damaged parts
Welding detection: too much tin, too little tin, side standing, tombstone, tin bridge, empty soldering, tin beads ,
raised legs, soldering after wave soldering (including plug-ins)
PCB/FPC size range 50*50mm (min) ~ 450*600mm (max)
PCB/FPC thickness
range
0.3 to 5mm
PCB/FPC clamping
system edge
clearance
TOP: 3.5mm Bottom: 3.5mm
Greater PCBA/FPCA
weight
3KG (overweight can be customized)
PCB/FPC curvature <5mm or 2% of PCB diagonal length
PCB/FPC upper and
lower clear height
PCB/FPC top side: 120mm PCB/FPC bottom side: 40mm
smallest component 3.45μm: 01005chip & 0.3 pitch IC
Barcode function Automatic barcode recognition (1D or 2D code)
Special features
Supports automatic program retrieval, multi-connected board multi-program detection function, front and back
program detection function; can check 0-359° rotating parts (unit is 1°).
remote control
Realize remote operation through TCP/IP network, view, start or stop machine operation, modify programs and
other operations anytime and anywhere
Server mode Using a central server, several AOI data can be centrally and uniformly managed.
SPC statistics
Record test data throughout the process and perform statistics and analysis. Production status and quality analysis
can be viewed in any area, and file formats such as Excel and txt can be output.
