G -S162-03 0805-001 DD-1 illust-1 カッタ部 B CUTTER SECTION B Fig. DD-1 ベースフレーム Base Frame 59 36 6 42 5 37 15 49 14 53 22 28 21 67 63 . 55 . 58 17 58 66 62 . 54 . 32 66 62 . 54 . 59 1 65 61 . 52 . 2 31 57 25 59 8 32 57 66 62…
G -S162-03
1004-003
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
DC-1
DC-1 list-1
1 6301370385 COVER 1 829DC-010-001 211A9793
2 6301370392 COVER 1 829DC-010-002 211A9794
3 6301605746 COVER 1 829DC-010-003 211AC453
5 6301370521 COVER 1 829DC-010-005 211A9804
6 6301375748 COVER 1 829DC-010-006 211A9872
8 6301403618 COVER 1 829DC-010-008 211AA158
9 6301379067 BLOCK 1
829D-A010420-A001-09
211G4137
10 6301379098 PLATE 1
829D-A010420-A001-10
211DA675
11 6301379074 PLATE 1
829D-A010420-A001-11
211DA673
14 6301433363 PLATE 1 0 829DC-010-014 211DB394
14 6301403236 PLATE 1
829D-A010420-A001-23
211DB023
15 6301370309 PLATE 1 829DC-010-015 211DA584
17 6301370378 PLATE 2 829DC-010-017 211DA586
21 6301365602 BRACKET 1 829DC-010-021 211F9663
22 6301380391 BRACKET 1 829DC-010-022 211F9817
25 6301372648 BRACKET 1 829DC-010-025 211F9758
26 6301380414 BRACKET 1 829DC-010-026 211F9819
27 6301403649 BLOCK 1 829DC-010-027 211G4318
28 6301403656 BLOCK 1 829DC-010-028 211G4319
31 6301260068 NAME PLATE,INDEX 1 829DC-010-231 6P460124
32 6301370217 BLOCK 2 829DC-010-032 211G4069
33 6301370224 BLOCK 2 829DC-010-033 211G4070
36 6301380384 BASE 1 829DC-010-056 210A2400
37 6301371924 FRAME 1 829DC-010-057 210B3901
42 6301538662 SUPPORT 1 829DC-010-072 211K3356
44 6301316512 PIPE FITTINGS 1
829D-A010420-A001-04
225F0612
46 6300041002 PIPE FITTINGS 1
829D-A010420-A001-06
225F0141
49 6301366906 GUIDE 1 829DC-010-049 212A2219
51 6300007503 BOLT,HEX-SCT 2 M3X6 221A0005
52 6300007527 BOLT,HEX-SCT 5 M3X10 221A0007
53 6300007619 BOLT,HEX-SCT 8 M4X8 221A0016
54 6300007619 BOLT,HEX-SCT 8 M4X8 221A0016
55 6300007725 BOLT,HEX-SCT 4 M5X6 221A0027
57 4110505004 SCR TRS 3X6 10 M3X6 TRS 221E0529
58 4110511708 SCR TRS 4X6 4 M4X6 TRS 221E0532
59 4111408007 SCR TRS 5X6 10 M5X6 TRS 221E0536
60 4110022600 SCR FLT 3X6 6 M3X6 FLT 221D0216
61 4111412806 WASHER SPR 3 5 7 SW3 221H0281
62 4111412905 WASHER SPR 4 8 SW4 221H0284
63 4111416705 WASHER SPR 5 4 SW5 221H0287
65 4111413902 WASHER V 3X7X0.5 5 7 FW3 221H0312
66 4111414008 WASHER V 4X9X0.8 8 FW4 221H0315
67 4111414107 WASHER V 5X10X1 4 FW5 221H0318
GXH-1JS
G -S162-03
G -S162-03
0805-001
DD-1 illust-1
カッタ部
B CUTTER SECTION B
Fig. DD-1
ベースフレーム
Base Frame
59
36
6
42
5
37
15
49
14
53
22
28
21
67
63
.
55
.
58
17
58
66
62
.
54
.
32
66
62
.
54
.
59
1
65
61
.
52
.
2
31
57
25
59
8
32
57
66
62
.
54
.
33
33
57
3
66
62
.
54
.
58
17
53
27
59
26
Notice 1)
Notice 1) Because the linear guide can not be replaced, it is
not included
in the available items to be ordered.
44
46
9
1
1
60
10
65
61
.
52
.
65
61
.
51
.
G -S162-03
1004-003
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
1 6301370385 COVER 1 829DD-010-001 211A9793
2 6301370392 COVER 1 829DD-010-002 211A9794
3 6301605814 COVER 1 829DD-010-003 211AC456
5 6301370514 COVER 1 829DD-010-005 211A9803
6 6301375731 COVER 1 829DD-010-006 211A9871
8 6301403618 COVER 1 829DD-010-008 211AA158
9 6301379067 BLOCK 1
829D-A010420-A001-09
211G4137
10 6301379098 PLATE 1
829D-A010420-A001-10
211DA675
11 6301379074 PLATE 1
829D-A010420-A001-11
211DA673
14 6301433363 PLATE 1 0 829DD-010-014 211DB394
14 6301403236 PLATE 1
829D-A010420-A001-23
211DB023
15 6301370309 PLATE 1 829DD-010-015 211DA584
17 6301370378 PLATE 2 829DD-010-017 211DA586
21 6301365596 BRACKET 1 829DD-010-021 211F9662
22 6301380407 BRACKET 1 829DD-010-022 211F9818
25 6301372648 BRACKET 1 829DD-010-025 211F9758
26 6301380421 BRACKET 1 829DD-010-026 211F9820
27 6301403649 BLOCK 1 829DD-010-027 211G4318
28 6301403656 BLOCK 1 829DD-010-028 211G4319
31 6301260068 NAME PLATE,INDEX 1 829DD-010-231 6P460124
32 6301370217 BLOCK 2 829DD-010-032 211G4069
33 6301370224 BLOCK 2 829DD-010-033 211G4070
36 6301380384 BASE 1 829DD-010-056 210A2400
37 6301371917 FRAME 1 829DD-010-057 210B3900
42 6301538662 SUPPORT 1 829DD-010-072 211K3356
44 6301316512 PIPE FITTINGS 1
829D-A010420-A001-04
225F0612
46 6300041002 PIPE FITTINGS 1
829D-A010420-A001-06
225F0141
49 6301366906 GUIDE 1 829DD-010-049 212A2219
51 6300007503 BOLT,HEX-SCT 2 M3X6 221A0005
52 6300007527 BOLT,HEX-SCT 5 M3X10 221A0007
53 6300007619 BOLT,HEX-SCT 8 M4X8 221A0016
54 6300007619 BOLT,HEX-SCT 8 M4X8 221A0016
55 6300007725 BOLT,HEX-SCT 4 M5X6 221A0027
57 4110505004 SCR TRS 3X6 10 M3X6 TRS 221E0529
58 4110511708 SCR TRS 4X6 4 M4X6 TRS 221E0532
59 4111408007 SCR TRS 5X6 10 M5X6 TRS 221E0536
60 4110022600 SCR FLT 3X6 6 M3X6 FLT 221D0216
61 4111412806 WASHER SPR 3 5 7 SW3 221H0281
62 4111412905 WASHER SPR 4 8 SW4 221H0284
63 4111416705 WASHER SPR 5 4 SW5 221H0287
65 4111413902 WASHER V 3X7X0.5 5 7 FW3 221H0312
66 4111414008 WASHER V 4X9X0.8 8 FW4 221H0315
67 4111414107 WASHER V 5X10X1 4 FW5 221H0318
GXH-1JS
G -S162-03
DD-1
DD-1 list-1
