G -S162-03 1004-003 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE D-4 D-4 list-1 363 6301494012 CORD 1 829F--010-163 4W203676 364 6301494029 CORD 1 829F--010-164 4W203677 371 6301494036 CORD 1 829B--010-251 4…
G -S162-03
0805-001
D-4 illust-1
部品認識部
RECOGNITION SECTION
Fig. D-4
ケーブル
Cable
363
364
See Fig. B-1
Key No.70
See Fig. D-2
Key No.161
See Fig. D-2
Key No.161
371
381
372
See Fig. BL-6
Key No.589
See Fig. BL-6
Key No.587
X0710
X0711
X0801
X0802
X0901
X0902
X0901
X0902
X0943
G -S162-03
1004-003
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
D-4
D-4 list-1
363 6301494012 CORD 1 829F--010-163 4W203676
364 6301494029 CORD 1 829F--010-164 4W203677
371 6301494036 CORD 1 829B--010-251 4W203678
372 6301494081 CORD 1 829B--010-252 4W203683
381 6301510521 CORD 1
829D-A010420-A151
4W203821
GXH-1JS
