SIPLACE Pro 15.2 (R18-1) / Version Description 01/2019 Edition
3
Contents
1 Introduction 5
1.1 System Overview ................................................................................................. 6
2 Scope of Delivery 7
2.1 Packages ............................................................................................................. 7
2.2 Languages ........................................................................................................... 7
2.3 Licenses ............................................................................................................... 8
3 Prerequisites 10
3.1 Supported Station Software Versions and Machine Types ................................ 10
3.2 Supported DEK Printer Software Versions and Printer Types ........................... 11
3.3 Supported Feeder Types ................................................................................... 12
4 Features of SIPLACE Pro 15.2 13
4.1 Support of Production Planner ........................................................................... 13
5 Features of SIPLACE Pro 15.1 14
5.1 SIPLACE TX V2 – New Placement Machine ..................................................... 14
5.2 SIPLACE C&P20 P2 – New Placement Head ................................................... 14
5.3 New X-Feeders .................................................................................................. 14
5.4 SIPLACE CA4 V2 – Fiducials on Conveyor Rails .............................................. 15
5.5 Support of DEK Version 10 with ASM Printer Programming 2.0 ....................... 15
5.6 Linear Dipping Unit 2 X – New Dipping Module ................................................. 15
5.7 Front-Back-Offset Measurement........................................................................ 15
5.8 Copy Feeders and Nozzles Feature – Extension .............................................. 16
5.9 CAD Data Import – Supported Formats ............................................................. 17
5.10 LED Pairing – Separate Package in SIPLACE Pro Installation ......................... 17
6 Features of SIPLACE Pro 15.0 18
6.1 New Fixed Rail Positions ................................................................................... 18
6.2 Making Equal Cycle Times for Left and Right Lane ........................................... 18
6.3 "The Hermes Standard" – New Communication Protocol .................................. 19
6.4 Line Configuration with Inspection Systems and AOI Devices .......................... 20
6.5 New Placement Force – Very Low Force in Placement, Pickup and
Dipping Processes ............................................................................................. 20
6.6 SEMO CRF80 – New Tape Feeder ................................................................... 20
6.7 External Barcode Reader in the Middle of the Line ........................................... 20
6.8 Barcode Conditions for Traceability Purposes ................................................... 21
6.9 BOM-Merger: Automatic Component Shape Linking ......................................... 21
7 Restrictions 22
8 Troubleshooting 25
8.1 Problems and Solutions ..................................................................................... 25
9 Appendix 26
9.1 ASM Error Reporter Service .............................................................................. 26
SIPLACE Pro 15.2 (R18-1) / Version Description 01/2019 Edition
5
1 Introduction
SIPLACE® Pro 15.2 (R18-1) is the programming system for SIPLACE placement. The placement
programs for the placement lines are prepared, generated and optimized with SIPLACE Pro. The
Release-Tag displays in which ASM Release the current product has been released.
Example: (R18-1) –> 1. Release, 2018.
Additionally, the SIPLACE Pro programming system supports DEK printing solutions. ASM Printer
Programming extends the existing SIPLACE Pro programming system by adding functionality for
editing print process data for DEK printing systems. The SIPLACE Pro programming system allows
preparing, optimizing and downloading printing programs. The ASM Printer Programming license
can be ordered separately, item no: [00117815-xx].
NOTICE
Please note the following:
As a user of the statistic functionalities of ASM’s software in this ASM’s product, you may
process personal data. Processing - including analyzing - personal data is subject to
data protection and other laws, which might impose restrictions and that might differ by
country. You are responsible to ensure that such processing is performed in compliance
with data protection and other laws applicable to you and your company. We therefore
would like to urge you to consult your supervisor or your legal department as regards the
data protection and other legal requirements to be followed.
