AirJet
®
594 CRD-SAC 
TECHNICAL DATA SHEET
5
www.dct.cleaning
Power supply 400V, 32A, 50Hz (3+N+PE) UL 400V, 32A, 60Hz* (3+N+PE)
Pmax 9,5 kW 9.5 kW
Connection to central air pressure Pipe Ø 10 mm Pipe ID 0.394 in
Recommended working pressure 4,5 – 6 Bar 65.25 – 87 PSI
Compressed air quality 3. Class ** 3. Class **
Exhaust pipe diameter Ø 100 mm ID 3.94 in
Exhaust pipe capacity 380 m
3
/h 13 400 ft
3
/hod
Minimum liquid for rst run 2 x 100 l 2 x 26.4 gal
Service space required around the device 600 mm 23.6 in
* When using frequency convertor
** According to the norm ISO 8573-1
INSTALLATION REQUIREMENTS
FRONT
VIEW
LEFT
VIEW
RIGHT
VIEW
BACK
VIEW
metric units imperial units
2536 mm
99.8 in
2390 mm
91.1 in
input air pressure Ø 10 mm
input air pressure ID 0.394 in
input el. power
1356 mm
53.3 in
1354 mm
45.8 in
166 mm
6.5 in
394 mm
15.5 in
AirJet
®
594 CRD-SAC 
TECHNICAL DATA SHEET
6
www.dct.cleaning
3 process chambers – semi-automatic solution
100% closed loop uid system
Cleaning and rinsing uid heating
Mechanical ltration
Hot air drying
Emergency stop button
Manipulation wheels – lockable
PLC controller + 5,7" touchscreen display
Spare parts (base kit)
STANDARD HARDWARE EQUIPMENT
Standard software language mutation – CZ, ENG
Liquid and lter replacement notication – cycle counting
Possibility of 5 programs – setting option
3 levels of logging – operator, maintenance, engineer
STANDARD SOFTWARE EQUIPMENT
AirJet
®
594 CRD-SAC 
TECHNICAL DATA SHEET
7
www.dct.cleaning
Adjustable timer of cleaning uid heating
Language mutation (CZE, ENG, GER, POL, CHI, RUS, ITA, SPA, MAY, HUN)
ONLINE access to cleaning device
OPTIONAL SOFTWARE EQUIPMENT
Cart with drip tray
Common uids draining – manual control
Filtration sandwich – external
Other optional equipment - the complete list of optional accessories will provide you DCT or the local distributor.
OPTIONAL HARDWARE EQUIPMENT
Mechanical basket
OPTIONAL ACCESSORY – FRAMES AND OTHERS
