Pr eventive Maintenance As part of maintaining continuous trouble-free use of this product, EFD recommends a few very simple preventative maintenance checks. 1. Periodically inspect tube-to-ﬁtting connections for proper …

Safety Warnings (continued)

Tipping and Dropping Hazard

BE SURE that the reservoir is placed on a hard, level surface and that all tubing lengths are of sufﬁcient

length to allow free motion of all movable components attached to the reservoir. DO NOT pull on tubing

to move the reservoir. Tipping the reservoir or otherwise supporting it on its side can cause the system

to run dry, resulting in possible pump damage.

If any system component parts are damaged or worn, they must be replaced with EFD supplied or

approved parts before returning them to service.

Tubing Safety

Pressurized tubing can be very dangerous. Tubing whose integrity is compromised due to any kind of

wear, damage, or misuse can develop a leak, spraying the contents of the tank at high pressure. This

spray can enter the eyes or cover the skin or cause other serious bodily injury, ﬁre, or property damage.

Before pressurizing the reservoir:

1. BE SURE all ﬂuid connections to the reservoir and pump are properly secured.

2. Examine all tubing for cuts, wear, bulges, and leaks. If any of these conditions exist, replace the

tubing immediately with EFD supplied or approved tubing. Do not try to repair a damaged tube.

3. BE SURE that the ﬂuid to be dispensed is compatible with the tubing. Contact the ﬂuid manufacturer

and conﬁrm that the ﬂuid is compatible with the polyethelene tubing supplied.*

*Use only Nordson EFD supplied polyethylene tubing for applications that use solvent-based liquids.

781RC MicroMark Recirculating Spray Marking System

4 www.nordsonefd.com info@nordsonefd.com +1-401-431-7000 Sales and service of Nordson EFD dispensing systems are available worldwide.

Preventive Maintenance

As part of maintaining continuous trouble-free use of this product, EFD recommends a few very simple

preventative maintenance checks.

1. Periodically inspect tube-to-ﬁtting connections for proper ﬁt. Secure as necessary.

2. Check tubing for cracks and contamination. Replace tubing as necessary.

3. Check all wiring connections for looseness. Tighten as necessary.

4. If front panel of 8040 controller requires cleaning, use a clean, soft damp rag with a mild detergent

cleaner. DO NOT USE strong solvents (acetone, MEK, etc.) as they will damage the front panel

material.

5. Dry running time should be kept to a minimum — less than 5 minutes.

6. During initial pump startup and priming, pump speed should be kept low until ﬂuid reaches the

pump. Once primed, pump speed can be increased.

Turn off pump enclosure assembly before servicing any 781RC recirculating system components.

CAUTION

Disconnect electrical

power before

servicing unit.

WARNING

Rotating Shaft.

Rotating parts and shaft can

cause severe injury. Lockout

power before removing gaurd

RoHS标准相关声明标准相关声明 (China RoHS Hazardous Material Declaration)

产品名称

Part Name

有害物质及元素

Toxic or Hazardous Substances and Elements

铅 

Lead

(Pb)

汞 

Mercury

(Hg)

镉 

Cadmium

(Cd)

六价铬

Hexavalent

Chromium

(Cr6)

多溴联苯

Polybrominated

Biphenyls

(PBB)

多溴联苯醚

Polybrominated

Diphenyl Ethers

(PBDE)

外部接口

External Electrical

Connectors

X 0 0 0 0 0

O:表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C

的标准低于SJ/T11363-2006限定要求。

Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is below the

limit requirement in SJ/T11363-2006.

X:表示该产品所含有的危险成分或有害物质含量依照EIP-A,EIP-B,EIP-C

的标准高于SJ/T11363-2006限定要求.

Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this part, according to EIP-A, EIP-B, EIP-C is above the

limit requirement in SJ/T11363-2006.

781RC MicroMark Recirculating Spray Marking System

5www.nordsonefd.com info@nordsonefd.com +1-401-431-7000 Sales and service of Nordson EFD dispensing systems are available worldwide.

ENCLOSURE

Cabinet Size (Length x Width x Depth): 25.4 x 20.3 x 10.2 cm (10 x 8 x 4")

Weight: 6.5 kg (14 lb, 6 oz)

Input AC (to power supply): 100–240 VAC ~ 50/60 Hz

Output Voltage (from power supply): 24 VDC — 2.7 Amp maximum

Power Requirements: 24 VDC — 2.0 Amp maximum

Ambient Operating Conditions: Temperature: 5° C to 45° C (41° F to 113° F)

Humidity: 85% RH at 30° C non-condensing

Height above sea level: 2000 meters max. (6562 ft)

NEMA Rating: Type 12 and 13

PUMP

Flow Capacity: Up to 88 liters per hour

Weight: 0.385 kg (13.6 oz)

Dimensions (Length x Max. Diameter): 130.5 x 56 mm (5.14 x 2.20")

Power Input: 24 VDC — 2.0 Amp maximum

Wetted Materials*: Pump body: 303SS

Gears: PEEK

Gasket: PTFE

Speed Control Signal: 0–10 volts DC

Pump Drive: Magnetic coupling

*Refer to speciﬁcations page in 781S installation guide for reference to wetted materials.

NOTE: Speciﬁcations and technical details are subject to engineering changes without prior notiﬁcation.
