Additive manufacturing (AM) is a technology that allows physical components to be made from virtual three-
dimensional (3D) computer models by building the component layer-by-layer until the part is complete. Additive
manufacturing, three-dimensional 3D printing (3DP), solid freeform fabrication (SFF), layered manufacturing
(LM), and rapid prototyping (RP) are collectively technologies that are can manufacture or fabricate a component
additively. Metal powders are the base materials for the production of metallic components through the
conventional powder metallurgy route or the emerging field of additive manufacturing. 3D printing filament
spools are also used as consumables.
ADDITIVE MANUFACTURING
STORAGE OF METAL POWDERS
Metal powders used in additive manufacturing are usually stored in containers around the printer or
ordinary closed cabinets until they are needed. However, in each opening of the container, ambient air and
moisture get into the container which affects the chemical and physical properties of the powder and cause
aging.
This issue cause deteriorating of powder and increasing of porosity. As a result, moisture and oxygen
affect the tensile strength, thermal resistance and corrosion resistance of materials, causing losses. When
it is stored in normal cabinets, metal powders can also react with the atmosphere inside the cabinet. Even if
the cabinet is emptied, ambient air and moisture flow will cause contamination and deterioration each time the
doors are opened.
X-Treme Series Powder Storage Cabinet has developed an innovative solution to solve this storage
problem. The cabinet works with a humidity and temperature control unit to measure humidity levels
continuously and delivers a high volume of nitrogen into the cabinet as soon as the doors are closed to remove
moisture from the air quickly. When it comes to set humidity and temperature value then it keeps the values
constant with the calculated amount of nitrogen that injected into the cabinet.
X-Treme Series Metal Powder and Filament Storage Cabinet offers the fastest dehumidification solutions
in the world, using desiccant dehumidification and smart nitrogen dehumidification technologies together in
perfect form.
X-Treme Series Metal Powder and Filament Storage Cabinet optimally adjusts the nitrogen gas used
thanks to its comprehensive software and sensitive sensors, keeping the humidity level to desired values,
and saving by minimizing the consumable usage level. Users can increase or decrease nitrogen gas pressure
according to process needs or it can be tailored to the process by changing the nitrogen gas injection settings
on the touch screen control panel. In this way, the user can decide which unit works how much
HYBRID SYSTEM
THE POWER OF NITROGEN
The use of nitrogen gas for dehumidification and storage is one of the oldest accepted methods in the
market for a long time. Nitrogen gas is purging into the cabinet and the air is thrown out of the cabinet.
Along with the air, moisture and oxygen are also thrown out. With that way, a moisture-free and oxygen-free
environment is provided.
Nitrogen is commonly used because it does not react when exposed to other gases, especially as
opposed to oxygen, which is highly reactive. Due to its chemical structure, nitrogen atoms need more
energy to break down and react with other substances. On the other hand, oxygen is a much more reactive
gas, as oxygen molecules break down easily. On the contrary, nitrogen gas enables obtaining non-reactive
environments where necessary.
The non-reactive feature of nitrogen is its greatest feature, and so this gas is used to prevent slow and
rapid oxidation. The electronics industry is an excellent example of this use because slow oxidation can occur
in the form of corrosion during the production of PCB’s (printed circuit boards) and other small components.
In this case, nitrogen is used to displace or replace air to better protect the end product.
X-Treme Series Metal Powder and Filament Storage Cabinet is an ideal environment, an effective
method, especially in cases where oxidation and corrosion are possible. Thanks to the positive pressure
it provides, it prevents moisture penetration into the dry cabinet and provides a safe environment for the
materials inside the dry cabinet.
sasdasdasd
Physical XSC-300-DN2 XSC-600-DN2 XSC-900-DN2 XTC-510-DN2 XLC-510-DN2
Net Volume
300 Lt 625 Lt 925 Lt 1250 Lt 1840 Lt
Net Volume (Thermal Insulated)
285 Lt 600 Lt 890 Lt 1215 Lt 1790 Lt
External Dimensions (WxHxD)
606x1128x750mm 606x1990x750mm 606x1990x1050mm 1200x1990x750mm 1200x1990x1050mm
Internal Dimensions (WxHxD)
603x792x630 mm 603x1654x630mm 603x1654x930mm 1197x1654x630mm 1197x1654x930mm
Internal Dimensions (WxHxD)
(Thermal Insulated)
584x772x630mm 584x1634x630mm 584x1634x930mm 1178x1634x630mm 1178x1634x930mm
Wight (Depends on configuration)
90 kg 134 kg 160 kg 190 kg 280 kg
Shelf Load Capacity
50 kg
Height From Ground
30 mm
Body Material
Electrostatic Painted Steel Body, Stainless Steel Interior Panel (AISI 430)
Door Glass
24 mm Insulated Glazing
Shelves and Drawers
2 pcs Stainless Steel 5 pcs Stainless Steel 5 pcs Stainless Steel 10 pcs Stainless Steel Optional
Electrical
Voltage
220 - 240 V AC 50 Hz - 110 V AC 60 Hz (±10%)
Current / Max. Power
10 A - 16 A (Maximum) / 2200 W Max
Average Power Consumption
50 W/h
Max. Power Consumption
1500 W/h
Operational
XSC-300-DN2 XSC-600-DN2 XSC-900-DN2 XTC-510-DN2 XLC-510-DN2
Humidity Set Range
0.5% - 95% RH (Ambient to Set Value)
Temperature Set Range (Optional)
2°C / 15°C / 45°C / 60°C / 100°C / 125°C (Ambient to Set Value)
Time to Reach to Set Humidity Level
<7 min. (values for 1% RH)
N2 (Nitrogen) Purity
%99,99
N2 (Nitrogen) Inlet Pressure Set
5-7 bar
N2 (Nitrogen) Inlet Connection Diameter 1/4 “
N2 (Nitrogen) Pressure Set
2 bar
N2 (Nitrohen) Flow
4.5-4.8 m³/h
Number of Doors
1 2 2 4 2
Door Lock
Automatic, Password Protected
Version 3.0 Software - Industry 4.0
Display -Control Panel
Type Touch Screen Display
Active Area 7" - (155 x 86mm)
Resolution 800 x 480 Pixel
Datalogger
Capacity 2 GB
Connection Type Wi-Fi (Wireless), Ethernet Cable (Network), USB Flash Disk
USB (AF Type) Connector Right and Left Side of the Cabinet
RMS (Remote Monitoring)
Monitoring via PC, Phone, Tablet
Connection Type Wi-Fi (Wireless), Ethernet Cable (Network)
Operational
XSC-300-DN2 XSC-600-DN2 XSC-900-DN2 XTC-510-DN2 XLC-510-DN2
Humidity Set Range
0.5% - 95% RH (Ambient to Set Value)
Temperature Set Range (Optional)
2°C / 15°C / 45°C / 60°C / 100°C / 125°C (Ambient to Set Value)
Time to Reach to Set Humidity Level
<7 min. (values for 1% RH)
N2 (Nitrogen) Purity
%99,99
N2 (Nitrogen) Inlet Pressure Set
5-7 bar
N2 (Nitrogen) Inlet Connection Diameter 1/4 “
N2 (Nitrogen) Pressure Set
2 bar
N2 (Nitrohen) Flow
4.5-4.8 m³/h
Number of Doors
1 2 2 4 2
Door Lock
Automatic, Password Protected
Cabinet Specifications
UV Light
Capacity 2 x 15W
Type UV-A
Socket Type G13
Lamp Type T8
Efficiency 20,6 uW/cm2
Wavelenght 350-390 nm
Control Manuel
Extraction
Capacity 350 m3/h
Control Manuel
Heater
Capacity 2 X750 W
Heater Type Electrical Heating Elements and Fans
Insulation Material Elastomeric Rubber Foam, Thermal Conductivity < 0.036 W/mK
Control Automatic
Shelf Capacity
Material Stainless Steel
Max Pcs / Cabinet 8 16 16 36 36
Min. Shelf Height 60mm
Mounting / Demounting With Shelf Holder Parts, No Tools Required
Customized Storage Options
(Depends on Customers’ Requirement)
Sliding Shelves
Sliding Shelf Dividers
Alarm Light Bar
Type Buzzer and Two-Colored Lights, Magnetic Base
Buzzer Noise Level 70 dB (A)
Light Type and Color Yellow and Red, 12 V, 5 W Lamps
Shape and Visibility Cylindrical, 360° View
Mounting Easy Attachable with Magnetic Base Plate, Built-In Screw Holes
Connection 4-Pin XLR Connector Behind Cabinet
Sensor Specifications
Relative Humidity Measurement
Location Cabinet Inside (Standard), Cabinet Outside (Optional)
Range 0 - 99% RH
Accuracy ± 0.3% RH (0…20% RH) ± 1.5% RH (20…99% RH) (After Calibrati-
on) (Indoor Sensor)
Resolution 0.01% RH < 10% RH - 0.1% RH > 10% RH (Indoor Sensor)
Temperature Measurement
Location Cabinet Inside (Standard), Cabinet Outside (Optional)
Range -20 - +125°C
Accuracy ± 0,5°C (at 25°C)
Resolution 0.1°C
Date & Time
Date (dd.mm.yy) and Time (hh:mm:ss) Display With Real Time Clock (RTC)
Alarm Function
Alarm Type
Standard Internal Buzzer, Optional Alarm Light Bar
Alarm Duration
Adjustable, Internal Buzzer: 5 - 255 sec. Alarm L. Bar: 1 - 60 min.
Humidity Level Alarm
Adjustable Offset: 0% RH - 40% RH
Temperature Level Alarm
Adjustable Time After Door Close: 1 - 60 minutes
Door Left Open Alarm
Adjustable Time to Alarm: 10 - 240 seconds
XSC-300-DN2 XSC-600-DN2 XSC-900-DN2 XTC-510-DN2 XLC-510-DN2
METAL POWDER and FILAMENT
STORAGE CABINET
