Operational
Humidity Set Range
0.5% - 95% RH (Ambient to Set Value)
Temperature Set Range (Optional)
15 °C - 45 °C - 60 °C - 100 °C (Ambient to Set Value)
Time to Reach to Set Humidity Level
<15 min. with one Dryer <7 min with double Dryer (values for 1% RH)
Specications
www.x-tremeseries.com
Measurements
Relative Humidity Measurement
Location Cabinet inside (Standard), Cabinet outside (Optional)
Range 0 - 99% RH
Accuracy
± 0.3% RH (0…20% RH) ± 1.5% RH (20…99% RH) (After Calibration)
(Indoor Sensor)
Resolution 0.01% RH < 10% RH - 0.1% RH > 10% RH (Indoor Sensor)
Temperature Measurement
Location Cabinet inside (Standard), Cabinet outside (Optional)
Range -20 - +110 °C
Temperature Measurement
Accuracy ± 0,5 °C (at 25 °C)
Resolution 0.1 °C
Date & Time Date (dd.mm.yy) and Time (hh:mm:ss) display with Real Time Clock (RTC)
Alarm Functions
Alarm Type Standard Internal Buzzer, Optional Alarm Light Bar
Alarm Duration Adjustable, Internal Buzzer: 5 - 255 sec. Alarm L. Bar: 1 - 60 min.
Humidity Level Alarm Adjustable Oset: 0% RH - 40% RH
Temperature Level Alarm Adjustable Time Aer Door Close: 1 - 60 minutes
Door Le Open Alarm Adjustable Time to Alarm: 10 - 240 seconds
Optional Features
Secondary Dehumidier Unit
Advantage 60% decrease in time to reach to set humidity level
Usage As Standby, Sharing Drying Task with Intervals
Heater
Capacity 2 x 750 W
Heating Type Electrical, Heating Elements and Fans
Insulation Material Elastomeric Rubber Foam, Thermal Conductivity < 0,036 W/mK
Control Automatic
Lighting
Location Interior
Capacity & Type LED Lamp for XS Line-Fluorescent daylight for XT and XL Line
Control Automated: Display Touch, Motion Sensor or Door Open Triggered
Light ON Time Aer Last Trigger, Adjustable: 0 - 240 minutes
Automatic Door Lock
Number of Locks 1 Lock per Door
Lock Type Automatic Door Locks by Password, Open / Locked Status Monitoring
Control Access Code Used as Password
Outdoor Sensor
Location Integrated to Body on Top of Right Side of Cabinet
Measurement Relative Humidity, Temperature
Specications Same as Cabinet Inside Sensor, Except Accuracy of ± 1.5% Rh
Alarm Light Bar
Type Buzzer and Two-Colored Lights, Magnetic Base
Buzzer Noise Level 70 dB (A)
Light Type and Colors Yellow and red, 12 V, 5 W lamps
Shape and Visibility Cylindrical, 360° View
Mounting Easy Attachable with Magnetic Base Plate, Built-In Screw Holes
Connection 4-Pin XLR Connector Behind Cabinet
Version 3.0 Soware - Industry 4.0
Display - Control Panel
Type Touch Screen Display
Active Area 7"- (155 x 86mm)
Resolution 800*480 Pixel
Datalogger
Capacity 2 GB
Connection Type Wi-Fi (Wireless), Ethernet Cable (Network), USB Flash Disk
USB (AF Type) Connector Right and Le Side of the Cabinet
RMS (Remote Monitoring)
Monitoring via PC, Phone, Tablet
Connection Type Wi-Fi (Wireless), Ethernet Cable (Network)
