0$&+,1( 3(5)250$1 &( 0$&+,1( &$3$%,/,7< 8.4 Installatio n Manu al Chapter Issue 2 May 03 8. Select St atis tics , Cpk - Process Cap abil ity . 9. Highli ght the required di mensions to outpu t and se…
0$&+,1(3(5)250$1&(
0$&+,1(&$3$%,/,7<
Chapter Issue 2 May 03 Installation Manual 8.3
6. Highlight sqy1.qcf file and select Open.
7. In the Record Filters Box, select sqy1 file and select O.K.
0$&+,1(3(5)250$1&(
0$&+,1(&$3$%,/,7<
8.4 Installation Manual Chapter Issue 2 May 03
8. Select Statistics, Cpk - Process Capability.
9. Highlight the required dimensions to output and select O.K.
0$&+,1(3(5)250$1&(
0$&+,1(&$3$%,/,7<
Chapter Issue 2 May 03 Installation Manual 8.5
10.View the Cp/Cpk values for the dimension illustrated ensuring the values are
within the specification. Select Next to view the further dimensions.
11. Repeat Steps 4 - 10 for filter group sqy2.qcf.
12.Record the following information in Section 21 of the Installation Checklist:
NOTE
On occasions no Cp/Cpk values are displayed for pressure and speeds due to
the small size of the error. Front Pressure and Rear Pressure are not recorded
for ProFlow only machines.
Virus Check
To perform an anti-virus check using a laptop computer carry out the following:
1. On the DEK machine, terminate the DEK program.
Detail Specification
X Alignment (Front)
Refer to the Configuration and
Despatch Procedure supplied
with the machine for the
values of Cp/Cpk.
X Alignment (Rear)
Y Alignment (Front)
Y Alignment (Rear)
θ Alignment (Front)
θ Alignment (Rear)
Front Pressure (See Note)
Rear Pressure (See Note)
Front Print Speed (See Note)
Rear Print Speed (See Note)
Detail Complete
Perform anti-virus check using the latest ver-
sion of virus checking software.
