DEK Spatulas DEK Spatulas are color-coded to ensure isolated use with appropriate materials and are an essential tool on the line. Light and durable, the polypropylene spatulas are shatterproof and flexible for long-last…
DEK Precision swabs
DEK Precision swabs have tips that are heat-sealed to the
handles to avoid contamination and adhesive compatibility
issues. The materials have been selected to provide the best
exibility and durability.
DEK Foam swabs
The foam swab is an excellent general-purpose swab for
cleaning small and conned areas. Its laundered foam head
possesses good absorbing capacity and cushioning. A compact,
rigid handle and round internal head core provide rm support.
DEK PRECISION SWABS
Part number Description Unit
SAP DEK
03134060 115840 Swab, foam LG. PDLE. HD 16 x 25 mm, L-13 cm Bag 50
03134059 115841 Swab, foam SLM - HD 12 x 25 mm, L-12 cm Bag 50
03134058 115842 Swab, foam NRW - HD 4 x 12 mm, L- 9 cm Bag 50
03134057 115843 Swab, foam MED - HD 6 x 19 mm, L-11 cm Bag 50
03129391 115846 Swab, cot wood handle SM HD 4 x1 2 mm L-14 cm Bag 1000
03133861 115850 Swab, laundered poly, SM HD 2 x 12 mm, L-7 cm Bag 50
03128530 431415 Cleanroom foam swab, ESD handle Bag 25
03128545 431416 Cleanroom foam swab, ESD handle Bag 100
DEK Precision swabs are designed, manufactured and packaged to provide
high-quality, economical solutions for various cleaning and maintenance
requirements in SMT and clean room applications, or anywhere that cleaning is
directly related to accuracy.
11
DEK Spatulas
DEK Spatulas are color-coded to ensure isolated use with appropriate materials and
are an essential tool on the line. Light and durable, the polypropylene spatulas are
shatterproof and flexible for long-lasting performance.
Features and benets:
■ Constructed of durable polypropylene
■ Shatterproof and flexible
■ Easy to grip
■ Less likely than metal spatulas to scratch the stencil surface
■ Easily cleaned with DEK pre-saturated wipes
■ Wide blade width for more efficient clearing of solder paste
Available in three, color-coded versions:
■ White for standard production purposes and use with lead-
containing paste
■ Lead-free green
■ Anti-static black
DEK SPATULAS
Part number Description Unit
SAP DEK
03128570 173737 White spatula Bag of 5
03128559 173788 Green spatula Bag of 5
03129776 173825 Black ESD spatula Bag of 5
12
|
Process Support Products
|
ASM: Stencils from the global No. 112
|
Process Support Products
|
ASM Consumables
DEK Solder paste nozzles easily snap into place, making the
cartridge immediately ready for use with on-board printer auto-
dispense technologies. These easy-to-use nozzles eliminate
clean-up of internal threads and solder paste drip, which are
common side eects of threaded dispense tip installation.
With this unique design, manufacturers can reduce process
costs, lower material waste and limit operator intervention.
Features and benets:
■ Color-coded: Visual identification of leaded and lead-free
solder pastes.
■ Non-drip: Paste flow is more controlled and excess material
reduced; ‘X’ low profile promotes paste mixing during solder
bead deposition.
■ Disposable: Simple, reduced-cost nozzles can be disposed
of with the empty solder paste tube. Eliminates messy, time-
consuming nozzle changes. Compatible with SEMCO
®
type
paste tubes.
■ Low waste and anti-mix strategy compliant: Compact format
reduces the amount of paste ‘in transit’ through the nozzle.
Disposable design ensures no cross contamination of paste
types.
DEK SOLDER PASTE NOZZLES
Part number Description Unit
SAP DEK
03131635 800120 Paste nozzles green (lead-free) 500
03131636 800125 Paste nozzles red (lead-rich) 500
03128678 800121 Paste nozzles green evaluation pack 25
03128629 800126 Paste nozzles red evaluation pack 25
DEK Solder paste nozzles
DEK Solder paste nozzles have been designed to facilitate solder
paste cartridge changeover more cleanly and efficiently than
conventional re-usable nozzles.
13
