4 New Functions in Feeder Manager 3.3
4.1 X-FVS Integration Support
This function provides Feeder Manager integration with the new X Feeder Test Station and XFVS
software.
Requirements:
● The Feeder Manager software has to be installed on the same computer connected to the X
Feeder Test Station.
● The XFVS software has to be installed on the X Feeder Test Station. The software is available
in the Software Download Center under Tools and Drivers.
● Enable the Option Export test result to feeder manager in the Settings view of the XFVS
software.
When testing the pick-up position of an X Feeder using the X Feeder Test Station, a test result file
is created and saved into a transfer directory.
Refer to the Feeder Manager 3.3 Getting Started [00198178-04] for more details.
4.2 New Feeder Type Support
The following new feeder types are supported for high speed machines TX V2:
Order number
Name
141478
SmartFeeder 4mm Xi
141498
SmartFeeder 4mm Xi Splice
141480
SmartFeeder 8mm Xi
141500
SmartFeeder 8mm Xi Splice
141479
SmartFeeder 2x8mm Xi
141499
SmartFeeder 2x8mm Xi Splice
Import the new feeder types via the New Feeder Type Import view in the Settings dialog, see
Feeder Manager 3.3 Getting Started [00198178-04].
