1-C 本体部 Main Body パーツレイアウト Kit No. キット品 番 Kit Name キット名称 KXFX045AA00 ｾｸｼｮﾝNo. PARTS LAYOUT Section No. M5
Ref
No.
Remarks
R
1
Q't
y
1-B
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
KXFX045AA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
SHAFT
2
1 KXFB02GCB01
TARGET
2
2 KXFB03KAA01
PLATE
4
3 KXFB02GLA00
PLATE
2
4 KXFB02GMA01
BLOCK
2
5 KXFB02GNA00
PLATE
2
6 KXFB02GPA01
BRACKET
2
7 KXFB09VDA00
BRACKET
1
8 N210096318AA
TRAY
2
9 KXF0CGAAA00 195391A-62
SHEET
2
10 KXF0DKNAA00 Hanenite sponge sheet(DA 0DKNA)
FRAME
2
11 N510001361AA SFF-244 L=77
BOLT
4
12 N510017461AA
Hexagon socket head cap screw M6X95-10.9 A2J (Trivalent)
WASHER
6
13 KXF0CP7AA00 URWH20-10-5
COLLAR
4
14 KXF0CP3AA00 NCLB6-10-18.5
WASHER
6
15 KXF0CPBAA00 WSSB20-6-3
WASHER
6
16 KXF0CXCAA00 WSSB20-10-2
COLLAR
2
17 KXF0CXDAA00 NCLB6-10-31.5
PIN
2
18 KXF0CXMAA00 1017003-80020
M4
1-C
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
KXFX045AA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
M5
Ref
No.
Remarks
R
1
Q't
y
1-C
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
KXFX045AA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210051558AA
MANIFOLD
1
2 KXFX061FA00
MANIFOLD
2
3 N510028350AA VV5QZ12-03-X132
BLOCK
2
4 KXF0A7RAA00 VQ1000-FPG-C6C6
JOINT
2
5 KXF02DLAA00 KQU04-06
RING
2
6 KXF089MAA00 R4X0.5
JOINT
1
7 KXF0DUAAA00 KCE08-00
SPACER
2
8 N510017094AA CB-320E
BOLT
2
9 N510017332AA
Hexagon socket head cap screw M3X50-10.9 A2J (Trivalent)
RING
1
10 KXF08ZYAA00 R2.5X0.5
BASE
1
11 KXF0CHGAA00 VV5QZ12-06C
VALVE
2
12 KXF09X2AA00 VQZ1121-5MO-C4
VALVE
2
13 KXF09X3AA00 VQZ1121-5MO-C6
VALVE
1
14 KXF0DR4AA00 VQZ1421-5MO-M5
VALVE
1
15 KXF0DR3AA00 VQZ1421-5MO-C6
JOINT
2
16 KXF09QCAA00 KQ2P-04
JOINT
3
17 KXF02B7AA00 KQH08-01S
SILENCER
6
18 KXF00WBAA00 AN110-01
PLUG
9
19 KXF09FYAA00 R(PT)1/8
SPEED-CONTROLLER
2
20 KXF0080AA00 AS1311F-M5-06
MANIFOLD
2
21 KXF0A50AA00 VV5QZ12-03C
VALVE
6
22 N510029538AA VQZ1321Y-5MO-C6
M6
