Standard
Nozzle Part #
PEEK
Nozzle Part #
Description Orifice Geometry Ball Size
Standard fluid body assembly
7361725 n/a Fluid body assembly 50 µm E 3.0S
7362574 7363321 Fluid body assembly 50 µm E 3.0S
7362575 7363322 Fluid body assembly 100 µm D 3.0S
7362576 n/a Fluid body assembly 200 µm D 3.0S
7362577 7363324 Fluid body assembly 50 µm E 5.0S
7362578 7363325 Fluid body assembly 100 µm E 5.0S
7362579 7363326 Fluid body assembly 150 µm E 5.0S
PEEK fluid body assembly
7362580 7363327 Fluid body assembly 300 µm E 5.0S
7362581 7363328 Fluid body assembly 100 µm D 5.0S
7362582 7363329 Fluid body assembly 150 µm D 5.0S
7362583 n/a Fluid body assembly 200 µm D 5.0S
7362584 7363331 Fluid body assembly 300 µm D 5.0S
7362585 7363332 Fluid body assembly 400 µm D 5.0S
7362586 7363333 Fluid body assembly 600 µm D 5.0S
4
PICO
Pµlse
Modular, Exchangeable System Parts
Partial listing of exchangeable components only. Consult EFD for full listing of available parts.
Flat Nozzle Fluid Body Assemblies
Extended Nozzle Fluid Body Assemblies
P7 fluid body assembly
P7*
Nozzle Part #
P30**
Nozzle Part #
Description Orifice Geometry Ball Size
7362703 n/a Fluid body assembly 50 µm E 3.0S
7362704 n/a Fluid body assembly 100 µm D 3.0S
7362705 n/a Fluid body assembly 200 µm D 3.0S
7362706 7363238 Fluid body assembly 50 µm E 5.0S
7362707 7363239 Fluid body assembly 100 µm E 5.0S
P30 fluid body assembly
7362708 7363240 Fluid body assembly 150 µm E 5.0S
7362709 7363241 Fluid body assembly 300 µm E 5.0S
7362710 7363242 Fluid body assembly 100 µm D 5.0S
7362711 7363243 Fluid body assembly 150 µm D 5.0S
7362712 7363244 Fluid body assembly 200 µm D 5.0S
7362713 7363245 Fluid body assembly 300 µm D 5.0S
7362714 7363246 Fluid body assembly 400 µm D 5.0S
7362715 7363247 Fluid body assembly 600 µm D 5.0S
*P7 nozzles extend 7 mm from the standard at nozzle length.
**P30 nozzles extend 30 mm from the standard at nozzle length.
A Nordson EFD application specialist will help select the best
uid body assembly for optimal dispensing performance.
5
Fluid Inlet Fittings
Part # Description
7362606
Fitting: M5 x female Luer lock, straight, stainless steel (includes Viton
®
O-ring)
7361303: O-rings: 5 x 1 mm, Viton, 10 pc
7361681: O-rings: 5 x 1 mm, FFKM, 3 pc
7363340
Fitting: M5 x female luer lock, straight, PEEK (includes FFKM O-ring)
7361303: O-rings: 5 x 1 mm, Viton, brown, 10 pc
7361681: O-rings: 5 x 1 mm, peruoroelastomer (FFKM), black, 3 pc
7020669 Fitting: M5 x 3/32" ID barb, stainless steel
7020671 Fitting: M5 x 1/8" ID barb, stainless steel
7020673 Fitting: M5 x 1/8" ID barb, stainless steel, elbow
7361498 Fitting: M5 x 35 mm male-female extension, stainless steel
7361645 Flat washers, M5 tting, EPDM, 10 pc (for legacy M5 ttings)
Extended Cone Nozzle Fluid Body Assemblies
P7*
Nozzle Part #
P30**
Nozzle Part #
Description Orifice Geometry Ball Size
7366300 n/a Fluid body assembly 50 µm E 3.0S
7366301 n/a Fluid body assembly 70 µm E 3.0S
7366302 n/a Fluid body assembly 50 µm E 5.0S
7366303 7366306 Fluid body assembly 70 µm E 5.0S
7366304 7366307 Fluid body assembly 100 µm E 5.0S
7366305 7366308 Fluid body assembly 150 µm E 5.0S
*P7 nozzles extend 7 mm from the standard at nozzle length.
**P30 nozzles extend 30 mm from the standard at nozzle length.
P7 cone nozzle fluid body assembly
P30 nozzle cone fluid body assembly
For Nordson EFD sales and service in over 40 countries,
contact Nordson EFD or go to www.nordsonefd.com.
Global
800-556-3484; +1-401-431-7000
info@nordsonefd.com
Europe
00800 7001 7001
infoefd.europe@nordsonefd.com
Asia
China: +86 (21) 3866 9006; china@nordsonefd.com
India: +91 80 4021 3600; india@nordsonefd.com
Japan: +81 03 5762 2760; japan@nordsonefd.com
Korea: +82-31-736-8321; korea@nordsonefd.com
SEAsia: +65 6796 9522; sin-mal@nordsonefd.com
Viton is a registered trademark of E.I. DuPont.
©2024 Nordson Corporation v011824
Valve Extension Cables
Part # Description
7361298 2 m (6.6 ft) valve extension cable set
7361299 6 m (19.7 ft) valve extension cable set
7361300 9 m (29.5 ft) valve extension cable set
Accessories
Part # Description
7361295 Valve cleaning kit (includes brushes, cotton swabs, mini-reamers, and a magnifying loupe)
7361630
Latch release tool (opens the piezo actuator heater body; useful for installations with
limited side access to the valve)
