6 | SE3000-DD 3D SPI SE3000-DD 3D SPI | 7
Multi-Reflection Suppression®
The SE3000-DD oers unmatched accuracy with the
revolutionary Multi-Reflection Suppression® (MRS®)
technology by meticulously identifying and rejecting
reflections caused by shiny components.
Reflection based distortions
MRS is designed to Inhibit reflection-based distortions
from shiny and specular surfaces.
Enabling the highest possible inspection accuracy at production speeds.
(MRS®) Sensor Technology
Nordson TEST & INSPECTION has advanced the proprietary
Multi-Reflection Suppression (MRS) sensor to an even finer
resolution. The Ultra-High Resolution MRS sensor enhances
the SE3000 DD platform, delivering superior inspection
performance, ideally suited for the 0201 metric process and
microelectronic applications where an even greater degree
of accuracy and inspection reliability is critical.
With
MRS
Without
MRS
Standard
MRS Sensor
Ultra High
Resolution
MULTIPLE MRS SENSOR OPTIONS
8 | SE3000-DD 3D SPI SE3000-DD 3D SPI | 9
The SPI V5 series soware delivers
world-class user experience with its
intuitive interface, completely
changing the way users interact
with our system.
With full multi-touch experience, SPI
V5 series soware oers a range of
revolutionary features that enable
smarter and faster inspection.
Features Include
• Seamless integration of all applications -
Teach, Inspection, Defect Review and
Real-time SPC.
• Unlimited undo-redo and global search
options in Teach.
• Loads of smart, informative and relevant
charts that provide yield summary, FPY
information, hotspot display, top 10 pad
failures, historical panel and more.
• Easy, hassle-free operation using multi
touch, multi-selection, pinchzoom,
and pan-move options.
CyberPrint OPTIMIZER™ automatically optimizes the print process by
proactively analyzing accurate trend data - first-ever in the industry!
Pre-defined templates help you get started quickly while customizable
rules support perfect customization for specific product needs.
CyberPrint OPTIMIZER‘s predictive process improvement gets you
better yields and reduces downtime.
Award-Winning Intuitive Soware CyberPrint OPTIMIZER™ Ready
Real-time SPC.
Hot Spot Display.
Defect Correlation
SPI AOI AOI
FAIL
FAIL
FAIL
FAIL
FAIL FAIL
PASS PASS
PASS
Fast, scalable SPC solution
CyberReport™ oers full-fledged
machine-level to factory-level SPC
capability with powerful historical
analysis and reporting tools.
Factory-level SPC
Line-level SPC
Machine-level SPC
Yield
Failure analysis drives line optimization and auto tolerance changes
Defect Review Interface.
10 | SE3000-DD 3D SPI SE3000-DD 3D SPI | 11
MRS is an ideal technology solution for a wide range of applications
including those with very high quality requirements.
LED
Aerospace
Advanced Packaging
SMT Electronics
Advanced Socket Metrology
Automotive
Medical
Solder Paste
Defense
Semiconductor
High End Applications
