WPW 80F/3
Page 20 / 22 19.11.2021
Pos. Item no. Description Part marking
140 00320244-02 PRESSURE PLATE
141 00320245-02 CONTROL CAM
142 00320246-02 CONTROL CAM 2
143 00320377-02 PRESSURE ELEMENT
144 00324128-02 GUIDE UNIT HSR25HR1SS+598L-II
145 00845059-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 20-8.8
147 00320343-01 TOOTHED BELT SYNCHROFLEX
16AT5/420
WEAR PART
148 00306736-01 PROXIMITY SWITCH
3RG4/8X8MM/SN=3,0MM/1S
149 00304134-01 DIN912-M2,5 X 12-A2-70
150 00320586-02 LIMIT SWITCH WITH CABLE SPARE PART
151 00303924-01 PLASTIC SPRING 8.5*20*30 (90
SHORE A)
152 00320344-01 PLASTIC SPRING 20*8,5*20 (90
SHORE A)
153 00320304-04 HINGE SPARE
154 00326545S02 MOTOR WITH GEAR WHEEL SPARE PART
155 00303916-02 BALL HOIST DRIVE ACCORDING SPARE PART
156 00320236-02 SUPPORT FLANGE SPARE PART
157 00303917-01 SHAFT NUT
00323365-02 COVER PLATE LIFTING AXIS
00320142-03 CASING
165 00320532-03 REAR COVER PLATE SHEET
166 00320533-04 SIDE PANEL LEFT HAND
167 00306773-01 NB602-M5 X 10-10.9, ZINC-C.
168 00320534-02 SIDE PANEL RIGHT HAND
169 00306773-01 NB602-M5 X 10-10.9, ZINC-C.
170 00320535-04 MOTOR HOOD SPARE PART
171 00306773-01 NB602-M5 X 10-10.9, ZINC-C.
174 00302827-04 WPC-SIPLACE SERVO UNIT SPARE PART
175 00302851-01 WPC DISTRIBUTOR AXIS CARD SPARE PART
176 00302852-04 WPC CONTROL BOARD
BRAKE/SERVO PCB
SPARE PART
177 00302836S12 AXIS PC-BOARD (TRIPLE)
178 00303523S02 MACHINE CONTROLLER SPARE PART
WPW 80F/3
Page 21 / 22 19.11.2021
Pos. Item no. Description Part marking
179 00302994-02 SERVO AMPLIFIER 4Q-DC-PWM, 10A
R31=31K
SPARE PART
180 00307661-02 SERVO CONTROLLER
TRS120/10WPH
SPARE PART
181 00302850-01 BALLAST CIRCUIT NR.BSO789/120
182 00302997-02 POWER SUPPLY UNIT 5V, +/-15V,
24V, 130W
SPARE PART
183 00302956-02 BUS BOARD + WRAP CONNECTION
184 00302853-01 WPC BACKPLANE SERVO PCB SPARE PART
185 00302854-01 WPC BACKPLACE BALLAST CIRCUIT SPARE PART
186 00305308-01 THROTTLE 0,4 MH 20A Spare Part
188 00303521-01 BATTERY LITHIUM 3,6V MIGNON WEAR
189 00303510-01 PUSH BUTTON
190 00320064-03 SIPLACE MOUNTING PLATE
191 00320063-02 WPC MOUNTING PLATE
192 00302816-01 TRAFO 400/230 Y/D-65V/6,6A
193 00302817S01 AUTOMATIC CIRCUIT BREAKER
5SX2/3P/4A-AC
Spare Part
194 00304324-01 AUTOMATIC BREAKER 1-POL 10A Spare Part
195 00302815-02 RECTIFIER KB63 A2 B2U04-10 400V
10A
SPARE
196 00303535-01 WPC DISTRIBUTOR INPUTS
197 00320531-02 COVER EMERGENCY-OFF SPARE PART
198 00321531-04 COVER OFF EMERGENCY WPC 80 F
199 00306773-01 NB602-M5 X 10-10.9, ZINC-C.
200 00320590-02 WPC 80F/3 EMERGENCY OFF WITH
CABLE
201 00320592-02 WPC SIPLACE SWITCH SPARE PART
00320594-04 CABLE WPW 80F/3 Y241-W1, INPUT SPARE PART
00320596-03 CABLE WPW 80F/3 Y242-W2,W3 SPARE PART
00303062-02 WPC Y4-W5, POWER SUPPLY SERVO
00320133-02 WPC Y244-W6, INPUT BYTE 1
00320134-02 WPC Y245-W7, INPUT BYTE 2
00320135-02 PPC Y246-W8 DISTRIBUTOR INPUT
AXIS PCB
00303073-01 WPC Y4-W31,W32 CABLE SUPPLI
AXIS WPC
WPW 80F/3
Page 22 / 22 19.11.2021
Pos. Item no. Description Part marking
00303074-01 WPC 80F CABLE LIFTING AXIS
00321530-03 COMPONENTS TABLE FIXED F 80/3
203 00309728-06 TABLE PLATE COMPLETE
204 00308192-03 ANGLE LEFT SPARE PART
205 00301239-06 TRAFO COMPONENT FEEDER TABLE SPARE PART
206 00316406-01 TRANSFORMER 320VA
207 00301069-03 CABLE:TRAFO - POWER SUPPLY SPARE PART
208 00300379-05 CABLE: POWER F. COMPONENT
TABLE
209 00308200-02 ANGLE RIGHT SPARE PART
210 00316265S05 COMMUNICATION SYSTEM SIPLACE
80S
SPARE
211 00328703-01 CABLE : COMP. TABLE - LED SMD SPARE PART
212 00328753-03 CABLE:CONTROL SIGNALS,
COMPONENTS-TABLE
SPARE PART
213 00320150-02 DOCKING BAR FOR WPC RETROFIT KIT
214 00307282-02 TAPE WASTE CONTAINER SMALL SPARE PART
215 00321781-01 TAPE CONTAINER SIPLACE 80 SPARE PART
216 00335102S03 EMPTY TAPE GUIDE DUCT
COMPL.15MM
SPARE PART
217 00335098-02 BAFFLE INSIDE 15MM SHORT
218 00335100-01 GUIDE METAL OUTSIDE 15MM
SHORT
219 00308062-02 TRACK RULER SPARE PART
220 00320321-02 GUIDE RAIL, WPC SPARE PART
