KJJ/KJH-101 1 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev . Rank Level No. Part …
KJJ/KJH-1011
6
1
2
3
5
4
33
33
34
34
40
38
5
7
8
9
14
15
10
32
11
12
18
19
19
43
20
37
21
39
39
44
44
36
23
45
24
13
12
35
42
35
42
42
17
16
15
17
16
22
27
25
26
46
46
49
49
26
25
28
41
47
48
48
48
30
31
31
29
32
42
38
38
47
4
1
X-axis
Moving-axis
KJJ/KJH-1011
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KJJ-M652W-01 SENSOR, XORG 1 B
Í
39 98902-03006 SCREW, BINDING HEAD 4
2 KJJ-M652X-00 SENSOR, XOT 1 B
Í
40 91312-03008 BOLT HEX. SOCKET HEAD 4
3 KHW-M2291-00 BRACKET, SENSOR 1 /
Í
41 91312-04006 BOLT HEX. SOCKET HEAD 26
4 KHW-M2282-00 DOG, ORIGIN 1 /
Í
42 91312-04008 BOLT HEX. SOCKET HEAD 16
5 KHW-M2283-00 DOG, 2ND LIMIT 2 /
Í
43 91312-04020 BOLT HEX. SOCKET HEAD 2
6
KHN-M221A-A0 COVER. DUCT ASSY. 1 /
Í
44 91317-04008 BOLT HEX. SOCKET HEAD 6
7
KJJ-M2266-00 PLATE, NUT
1
/
Í
45
91317-06018 BOLT HEX. SOCKET HEAD
4 M6XL18
8
KJJ-M2267-A0 CABLE, DUCT
1
B
Í
46
91312-03008 BOLT HEX. SOCKET HEAD
6 M3X8
9
KJJ-M2268-00 BRACKET 1, TAPE
1
/
Í
47 91312-04006
BOLT HEX. SOCKET HEAD
12 M4X6
10 KJJ-M2269-00 BRACKET 2, TAPE 1 /
Í
48 98902-04006 SCREW BINDING HEAD 8
11 KHW-M226A-00 COVER, CABLE 1 /
Í
49 92902-03200 WASHER PLAIN 6
12 KV7-M226B-00 PLATE 2 /
Í
50
13 KJJ-M226C-00 PLATE, SPACER 1 /
Í
51
14 KJJ-M226D-00 PLATE, NUT 1 /
Í
52
15 KJJ-M220A-00 TAPE, X DUCT 1 /
Í
53
16 KJJ-M220B-00 TAPE 2, X DUCT 1 /
Í
54
17 KJJ-M220C-00 TAPE 3, X DUCT 1 /
Í
55
18 $US10
JOINT
2
/
56
19 $UL10
JOINT 2
/
Í
57
20 KGS-M2256-00
GRIP 1
/
Í
58
21 KHW-M22C5-00 COVER UNDER, X AXIS 1 /
Í
59
22 KHW-M2271-A0 X AXIS BS SUB ASSY 1 A A 60
23 90K63-511403 AC SERVO MOTOR 1 B
Í
61
24 KM0-M2220-00 COUPLING, X-AXIS 1 /
Í
62
25 KHW-M2248-00 DAMPER 2 /
63
26 KHW-M2249-00 SPACER 6 /
64
27 KHW-M22C1-00 COVER A, X AXIS 1 /
65
28 KHW-M22C2-00 COVER B, X AXIS 1 /
66
29 KHW-M22C3-00 COVER C, X AXIS 1 /
67
30 KHW-M22C4-00 COVER, COUPLING X 1 /
68
31 KV7-M7165-00 SEAL DON’T TOUCH 2 /
69
32 90990-01J032 BOLT HEX. SOCKET HEAD 8 70
33 92903-03100 WASHER, SPRING 4 71
34 92902-03600 WASHER, PLAIN 4 72
35 92902-04200 WASHER, PLAIN 4 73
36 92907-04200 WASHER, PLAIN 4 74
37 92907-10200 WASHER, PLAIN 1 75
38 90990-11J003 SCREW PAN HEAD W/W 6 76
4
1
X-axis
Moving-axis
KJJ/KJH-1011
20
21
14
15
16
17
19
20
18
20
19
20
21
18
20
20
15
14
16
17
15
15
14
14
16
16
17
17
13
19
6
11
6
11
10
6
5
6
5
2
12
1
12
2
1
3
4
13
3
4
13
9
8
7
4
2
Y-axis
Moving-axis
