P a g e | 17
UFT Ultra-Fine Tweezer Cartridges are compatible with CV-5200, CV-500 Systems
and CV-H4-UFT Ultrafine Tweezer Hand piece.
Temperature CV-Series Application
UFT-6
Temperature Sensitive
UFT-7
Most Standard
Please note the above temperatures are the maximum temperatures of the heater. The idle temperature is dependent on the geometry of
the cartridge.
These tips will provide data via the CV power supplies, but due to the nature of their application the Connection Validation function is not
required and therefore not enabled. All tweezer cartridges are sold per pair!
Ultra-Fine Tweezer Cartridge - Chisel
UFT-6CH9006S
UFT-7CH9006S
(W x L) 0.6 x 9 mm
Sold per pair
UFT-6CH9008S
UFT-7CH9008S
(W x L) 0.8 x 9 mm
Sold per pair
Ultra-Fine Tweezer Cartridge - Conical
UFT-6CN5502R
UFT-7CN5502R
Conical, Bent, for work under a microscope,
(ø x L) 0.2 x 5.6 mm,
Sold per pair
UFT-6CN5504R
UFT-7CN5504R
Conical, Bent, for work under a microscope,
(ø x L) 0.4 x 5.6 mm,
Sold per pair
UFT-6CN8004S
UFT-7CN8004S
Conical
(ø x L) 0.4 x 8.7 mm,
Sold per pair
Ultra-Fine Tweezer Cartridge - Power Wedge
UFT-6PW3150S
UFT-7PW3150S
Power Wedge, two-way use, tip and long side,
(ø x L) 0.31 x 5.0 mm,
Sold per pair
UFT-6PW2954C
UFT-7PW2954C
Power Wedge, two-way use, tip and long side,
(ø x L) 0.29 x 5.4 mm,
Sold per pair
675 °F/357 °C
775 °F/413 °C
P a g e | 18
DSC De-Solder Cartridges are compatible with MX-500, MX-5000, MX-5200 AND CV-5200,
CV-500 Systems – MX-DS1 and CV-H5-DS Hand pieces.
STDC De-Solder Cartridges are compatible with MX-500, MX-5000, MX-5200 Systems
and MX-DS1 Hand piece.
Temperature CV-Series
MX-Series
Application
DSC-6 STDC-0
Temperature Sensitive
DSC-7 STDC-1 / 7xxL
Most Standard
DSC-8
Ceramic and High Thermal Demand
DSC-9 STDC-8
Please note the above temperatures are the maximum temperatures of the heater. The idle temperature is dependent on the geometry of
the cartridge.
These tips will provide data via the CV series power supplies, but due to the nature of their application the Connection Validation function
is not required and therefore not enabled.
De-Solder Cartridges
A
B
C
DSC-xxxA / STDC-xxxL = Long Reach
Desolder Cartridge to remove
components form high density packed
PCBs.
STDC-002
0.64 mm
1.40 mm
11.43 mm
STANDARD
STDC-102
DSC-6CN0006S
DSC-7CN0006S
DSC-8CN0006S
DSC-9CN0006S STDC-802
STDC-003
0.76 mm
1.68 mm
11.17 mm
STDC-103
DSC-6CN0008S
DSC-7CN0008S
DSC-8CN0008S
DSC-9CN0008S
STDC-803
STDC-004
1.02 mm
1.78 mm
10.92 mm
STDC-104
DSC-6CN0010S
DSC-7CN0010S
DSC-8CN0010S
DSC-9CN0010S STDC-804
STDC-005
1.27 mm
2.03 mm
10.66 mm
STDC-105
DSC-6CN0013S
DSC-7CN0013S
DSC-8CN0013S
DSC-9CN0013S STDC-805
STDC-006
1.52 mm
2.29 mm
10.41 mm
STDC-106
DSC-6CN0015S
DSC-7CN0015S
DSC-8CN0015S
DSC-9CN0015S STDC-806
STDC-007
2.41 mm
3.18 mm
9.14 mm
STDC-107
DSC-6CN0024S
DSC-7CN0024S
DSC-8CN0024S
DSC-9CN0024S STDC-807
0.76 mm
1.68 mm
21.33 mm
LONG REACH
STDC-703L
DSC-6CN0008A
DSC-7CN0008A
DSC-8CN0008A
DSC-9CN0008A STDC-803L
1.02 mm
1.79 mm
21.08 mm
STDC-704L
DSC-6CN0010A
DSC-7CN0010A
DSC-8CN0010A
DSC-9CN0010A STDC-804L
1.27 mm
2.03 mm
20.82 mm
STDC-705L
DSC-6CN0013A
DSC-7CN0013A
DSC-8CN0013A
DSC-9CN0013A STDC-805L
675 °F/357 °C
775 °F/413 °C
875 °F/468 °C
950 °F/510
°C
www.metcal.com
Since 1982, Metcal has been a recognized worldwide leader in the electronics assembly
marketplace. As part of OK International, Metcal’s industry-leading position
addres
sing advanced technology in conduction soldering and rework has and will
continue to broaden to a full electronics bench tool single-source solution. Metcal
product lines currently include: hand soldering and desoldering, convection rework,
fume extraction and fluid dispensing tools.
