A- 80 A 35 P8 本体 ASSY-1 P8 Main assy-1 1 2 2 8 3 9 2 0 3 7 4 3 2 1 2 8 3 9 3 7 3 0 4 3 3 0 1 4 1 6 1 7 3 4 3 8 3 2 2 6 2 9 2 5 2 5 4 1 4 1 2 7 4 0 1 5 1 5 A B 1 8 2 3 2 4 A B 2 9 2 9 4 2 3 1 2 2 3 4 3 5 3 4 3 3 3 3 3 2 4…
A-79
A34
カバー ASSY-3
Cover assy-3
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
401-43860
BANK_COVER_ASM
ﾊﾞﾝｸｶﾊﾞｰ_ｸﾐ
1
2
401-43388
COVER_BANK_SENSOR_BR
ｶﾊﾞｰ_ﾊﾞﾝｸ_ｾﾝｻ_ﾌﾞﾗｹｯﾄ
(2)
3
401-43389
COVER_BANK_L
ｶﾊﾞｰ_ﾊﾞﾝｸ_L
(1)
4
SL-6051092-TN
SCREW M5 L=10
座金付き六角穴ﾎﾞﾙﾄ M5 L=10
(4)
5
SL-6041092-TN
SCREW M4 L=10
座金付き六角穴ﾎﾞﾙﾄ M4 L=10
(2)
6
401-43390
COVER_BANK_R
ｶﾊﾞｰ_ﾊﾞﾝｸ_R
(1)
7
SL-6051092-TN
SCREW M5 L=10
座金付き六角穴ﾎﾞﾙﾄ M5 L=10
(4)
8
SL-6041092-TN
SCREW M4 L=10
座金付き六角穴ﾎﾞﾙﾄ M4 L=10
(2)
9
401-43391
BANK_UP_SENSOR_BR
ﾊﾞﾝｸ_ｱｯﾌﾟ_ｾﾝｻ_ﾌﾞﾗｹｯﾄ
(2)
10
SL-6051092-TN
SCREW M5 L=10
座金付き六角穴ﾎﾞﾙﾄ M5 L=10
(2)
11
401-58792
FEEDER_FLOAT_JAM_SENSOR_ASM
ﾌｨｰﾀﾞｳｷ_JAM ｾﾝｻｸﾐ
1
12
401-28046
SENSOR_BRACKET_B
ｾﾝｻﾌﾞﾗｹｯﾄ B
(1)
13
SL-6040692-TN
SCREW M4 L=6
座金付き六角穴ﾎﾞﾙﾄ M4 L=6
(12)
14
SM-6030802-TN
SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
(12)
15
WP-0320501-SC
WASHER M3
ﾋﾗｻﾞｶﾞﾈ M3
(12)
16
HX-0070600-0A
MOUNT BASE
ﾏｳﾝﾄﾍﾞｰｽ
(8)
17
401-58787
SENSOR ASSY A (FEEDER FLOAT JAM)
SENSOR ASSY A (FEEDER FLOAT JAM)
(2)
18
401-58788
SENSOR ASSY B (FEEDER FLOAT JAM)
SENSOR ASSY B (FEEDER FLOAT JAM)
(1)
19
401-58829
FEEDER_SENSOR_STAND_L
ﾌｨｰﾀﾞｾﾝｻｽﾀﾝﾄﾞ L
(1)
20
401-58830
FEEDER_SENSOR_STAND_R
ﾌｨｰﾀﾞｾﾝｻｽﾀﾝﾄﾞ R
(1)
21
EZ4-716-434-21
TIE INSULOCK (AB150 BLACK)
ｲﾝｼｭﾛｯｸ ﾀｲ (AB150 ｸﾛ)
(10)
22
401-60564
SENSOR_BR_LI
ｾﾝｻﾌﾞﾗｹｯﾄ LI
(1)
23
401-60565
SENSOR_BR_RI
ｾﾝｻﾌﾞﾗｹｯﾄ RI
(1)
24
401-60566
SENSOR_BR_LO
ｾﾝｻﾌﾞﾗｹｯﾄ LO
(1)
25
401-60567
SENSOR_BR_RO
ｾﾝｻﾌﾞﾗｹｯﾄ RO
(1)
26
SM-6040802-TN
SCREW M4X0.7 L=8
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8
8
27
EZ1-492-199-22
SAFETY SW ASSY
SAFETY SW ASSY (ﾀﾞｲｼﾔ) R
1
28
EZ1-492-199-32
SAFETY SW ASSY
SAFETY SW ASSY (ﾀﾞｲｼﾔ) L
1
29
EZ1-771-841-11
SWITCH POWER (D2D-2000)
ﾃﾞﾝｹﾞﾝ ｽｲﾂﾁ (D2D-2000)
2
30
EZ2-672-385-01
FILTER (FL12) FAN
ﾌｱﾝ ﾖｳ ﾌｲﾙﾀ- (FL12)
4
31
EZ1-763-987-11
FAN (4715MS-20T-B5A-B01)
ﾌｱﾝ (4715MS-20T-B5A-B01)
4
32
EZ4-720-311-01
GUARD FAN (PG-47-02)
ﾌｱﾝ ｶﾞ-ﾄﾞ (PG-47-02)
4
33
EZ7-682-265-04
SCREW +K 4X16
ﾈｼﾞ +K 4X16
16
34
EZ7-684-024-04
N 4 TYPE 2
N 4 TYPE 2
32
35
EZ7-683-421-04
BOLT HEXAGON SOCKET 4X12
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ(C4X12)
16
A-80
A35
P8 本体 ASSY-1
P8 Main assy-1
1 2
2 8
3 9
2 0
3 7
4 3
2 1
2 8
3 9
3 7
3 0
4 3
3 0
1 4
1 6
1 7
3 4
3 8
3 2
2 6
2 9
2 5
2 5
4 1
4 1
2 7
4 0
1 5
1 5
A
B
1 8
2 3
2 4
A
B
2 9
2 9
4 2
3 1
2 2
3 4
3 5
3 4
3 3
3 3
3 2
4 2
3 4
3 6
3 4
2 2
3 1
4 2
3 4
2 9
2 9
B
A
4 0
2 7
4 1
4 1
2 5
2 5
2 9
2 6
3 8
3 4
1 7
1 6
1 4
1 2
2
3
2
2
3
2
2
3
2
2
3
2
1 3
1 1
1 3
1 1
1 0
5
1 0
4
1 0
1 3
1 1
1 0
2 4
2 3
1 8
B
A
1 5
1 5
3 4
3 4
4 2
3 4
C
D
C
D
1 5
9
1
7
9
1
7
8
6
1
6
8
1
1 9
1 9
A-81
A35
P8 本体 ASSY-1
P8 Main assy-1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
401-28046
SENSOR_BRACKET_B
ｾﾝｻﾌﾞﾗｹｯﾄ B
4
2
401-58787
SENSOR ASSY A (FEEDER FLOAT JAM)
SENSOR ASSY A (FEEDER FLOAT JAM)
4
3
401-58788
SENSOR ASSY B (FEEDER FLOAT JAM)
SENSOR ASSY B (FEEDER FLOAT JAM)
2
4
401-58829
FEEDER_SENSOR_STAND_L
ﾌｨｰﾀﾞｾﾝｻｽﾀﾝﾄﾞ L
1
5
401-58830
FEEDER_SENSOR_STAND_R
ﾌｨｰﾀﾞｾﾝｻｽﾀﾝﾄﾞ R
1
6
401-60564
SENSOR_BR_LI
ｾﾝｻﾌﾞﾗｹｯﾄ LI
2
7
401-60565
SENSOR_BR_RI
ｾﾝｻﾌﾞﾗｹｯﾄ RI
2
8
401-60566
SENSOR_BR_LO
ｾﾝｻﾌﾞﾗｹｯﾄ LO
2
9
401-60567
SENSOR_BR_RO
ｾﾝｻﾌﾞﾗｹｯﾄ RO
2
10
SL-6040692-TN
SCREW M4 L=6
座金付き六角穴ﾎﾞﾙﾄ M4 L=6
24
11
SM-6030802-TN
SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
24
12
SM-6040802-TN
SCREW M4X0.7 L=8
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8
8
13
WP-0320501-SC
WASHER M3
ﾋﾗｻﾞｶﾞﾈ M3
24
14
EZ4-113-099-01
CUSHION (1) URETHANE
ｳﾚﾀﾝ ｸﾂｼﾖﾝ (1)
4
装置構成により数量異なる
15
EZ2-580-593-01
SCREW +PSW M3X8
ﾈｼﾞ +PSW M3X8
10
16
EZ4-453-566-01
COLLAR
ｶﾗ-
4
17
EZ7-688-005-11
W 5 MIDDLE
W 5 MIDDLE
4
18
401-55050
FC-LED CONT PCB ASM
FC-LED CONT 基板組
2
装置構成により数量異なる
19
401-56349
STOPPER SPACER (LARGE)
ｽﾄｯﾊﾟｰｽﾍﾟｰｻ (LARGE)
2
20
401-56351
INNER COVER FL (P8)
ｲﾝﾅｰｶﾊﾞｰ FL (P8)
1
21
401-56352
INNER COVER FR (P8)
ｲﾝﾅｰｶﾊﾞｰ FR (P8)
1
22
401-56353
SENSOR BRACKET (P8)
ｾﾝｻｰﾌﾞﾗｹｯﾄ (P8)
2
23
401-56354
LED CTRL PWB BRACKET (L)
LED ｺﾝﾄﾛｰﾙｷﾊﾞﾝ ﾌﾞﾗｹｯﾄ (L)
2
24
401-56355
LED CTRL PWB BRACKET (R)
LED ｺﾝﾄﾛｰﾙｷﾊﾞﾝ ﾌﾞﾗｹｯﾄ (R)
2
25
401-56358
SILENCER (AN05-M5)
ｻｲﾚﾝｻ (AN05-M5)
4
26
401-56614
SOLENOID VALVE (SY3120) ASSY
ｿﾚﾉｲﾄﾞ ﾊﾞﾙﾌﾞ (SY3120) ASSY
2
27
401-60786
STOPPER BOX COVER (P8)
ｽﾄｯﾊﾟｰ BOX ｶﾊﾞｰ (P8)
2
28
EZ7-682-265-04
SCREW +K 4X16
ﾈｼﾞ +K 4X16
16
29
EZ7-683-404-04
BOLT HEXAGON SOCKET 3X8
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8
12
30
EZ7-683-421-04
BOLT HEXAGON SOCKET 4X12
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ(C4X12)
16
31
EZ7-683-422-04
BOLT HEXAGON SOCKET 4X14
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X14
4
32
EZ7-683-425-04
BOLT HEXAGON SOCKET 4X20
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X20
4
33
EZ7-683-419-04
BOLT HEXAGON SOCKET 4X8
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X8
8
34
EZ7-683-435-04
BOLT HEXAGON SOCKET 5X10
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X10
16
35
EZ1-492-199-22
SAFETY SW ASSY
SAFETY SW ASSY (ﾀﾞｲｼﾔ) R
1
36
EZ1-492-199-32
SAFETY SW ASSY
SAFETY SW ASSY (ﾀﾞｲｼﾔ) L
1
37
EZ1-763-987-11
FAN (4715MS-20T-B5A-B01)
ﾌｱﾝ (4715MS-20T-B5A-B01)
4
38
EZ1-771-841-11
SWITCH POWER (D2D-2000)
ﾃﾞﾝｹﾞﾝ ｽｲﾂﾁ (D2D-2000)
2
39
EZ2-672-385-01
FILTER (FL12) FAN
ﾌｱﾝ ﾖｳ ﾌｲﾙﾀ- (FL12)
4
40
EZ4-447-053-11
UNION (KQ2H06-M5N) HALF
ﾊ-ﾌ ﾕﾆｵﾝ (KQ2H06-M5N)
2
41
EZ4-447-110-01
UNION (KQ2L04-M5N) ELBOW
ｴﾙﾎﾞ ﾕﾆｵﾝ (KQ2L04-M5N)
4
42
EZ4-705-597-41
PIN (DIA. 5) PARALLEL
ﾍｲｺｳ ﾋﾟﾝ (ﾌｱｲ 5)
4
43
EZ4-720-311-01
GUARD FAN (PG-47-02)
ﾌｱﾝ ｶﾞ-ﾄﾞ (PG-47-02)
4
