2 Safety 2.2 Warning labels 24 Instruction Guide ASM ProcessLens Dual-lane 06/2018 Fig.9: Warning labels - Conveyor 1 W 208 [03009347-xx] 2 Conveyor control (under the cover) 2.2.3 Description of the warning labels 2.2.…
2 Safety
2.2 Warning labels
Instruction Guide ASM ProcessLens Dual-lane 06/2018 23
Fig.8: Warning labels - Power supply unit and voltage distribution board
1 W 206 [03009345-xx] 2 W-Hazardous-Voltage [03157800-xx]
3 W HS - Hot surface [03031926-xx] 4 W 204 [03009343-xx]
5 Label for the power supply unit cover
[03113903‑xx]
2 Safety
2.2 Warning labels
24 Instruction Guide ASM ProcessLens Dual-lane 06/2018
Fig.9: Warning labels - Conveyor
1 W 208 [03009347-xx]
2 Conveyor control (under the cover)
2.2.3 Description of the warning labels
2.2.3.1 Warning label W 201
Fig.10: W 201 [03009338-xx] (quantity per machine: 1)
Safe operation of the machine
Safe operation of the machine depends abso-
lutely on the operator being familiar with the In-
structor Guide and safety instructions and put-
ting them into effect.
See fig. "Warning labels front view" [}19]
2 Safety
2.2 Warning labels
Instruction Guide ASM ProcessLens Dual-lane 06/2018 25
2.2.3.2 Warning label W 81-00382
Fig.11: Warning label W 81-00382-xx (quantity per
machine: 1)
Hazardous Voltage
Contact may cause electric shock or burn.
► Turn off and lock out system power before
servicing.
See fig. "Warning labels front view" [}19]
2.2.3.3 Warning label – Laser class 2
Fig.12: W laser class 2 [03009347xx]
LASER RADIATION
Laser class 2
Acc. to IEC 60825-1:2014
► Do not look into beam!
See fig. "Warning labels - Conveyor" [}24]
2.2.3.4 Warning label W202
Fig.13: W202 [03009341-xx] (quantity per machine: 3)
See fig. "Warning labels front view" [}19], "Warning labels - front view - inside - part 1" [}21] and
"Warning labels - front view - inside - part 2" [}22]
DANGER
Danger to life from powerful magnetic fields inside the machine
When protective covers are opened inside the machine, the life of persons with the follow-
ing passive or active implants is put at risk:
► Pacemakers
► Defibrillators
► Insulin pumps, etc.
► At-risk people must not stand in the immediate vicinity of the machine.
