1 4 Head X-Ray Head KLC-1304 31 31 2 3 3 11 24 24 26 38 29 29 30 28 28 34 13 31 4 6 26 8 38 34 34 7 7 34 5 10 9 30 30 30 30 30 22 40 32 28 28 35 39 19 17 21 42 18 20 22 1 31 35 26 27 33 36 32 18 15 18 14 20 20 29 38 OL…
9
3
D Type X-Ray Detector
Moving-axis
KLC-1702
9
21
16
15
18
12
18
13
5
2
24
25
25
24
4
3
7
17
23
1
20
19
8
6
22
14
19
11
19
19
19
15
10
15
9
21
16
15
18
12
18
13
5
2
24
25
25
24
4
3
7
17
23
1
20
19
8
6
22
14
19
11
19
19
19
15
10
15
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KGJ-M1305-K0 HANDLE 1
2 KLC-M2824-10 PLATE,CDTE 3 1
3 KLC-M2826-00 STEP SCREW 1
4 KLC-M2827-00 ECCENTRIC PIN 1
5 KLC-M2855-00 BRKT.,SENSOR LY 1
6 KLC-M2861-10 PLATE,CAMERA 2 1
7 KLC-M2862-10 PLATE,CAMERA 1 1
8 KLC-M2863-10 BRKT.,HNS.1 1
9 KLC-M2864-00 BRKT.,HNS.3 1
10 KLC-M2865-10 COVER,HNS. 1
11 KLC-M2868-00 STAY,HNS. 1
12 KLC-M652E-10 SENSOR LY ORG ASSY 1
13 KLC-M652F-10 SENSOR LY OT ASSY 1
14 KLC-M71H2-20 X-RAY DETECTOR 1
15 90990-01J017 BOLT HEX,SOCKET HEAD 8
16 90990-01J039 BOLT HEX,SOCKET HEAD 4
17 90990-28J055 WASHER,PLAIN 6
18 91312-03008 BOLT HEX,SOCKET HEAD 4
19 91312-04006 BOLT HEX,SOCKET HEAD 8
20 91312-04008 BOLT HEX,SOCKET HEAD 4
21 91312-05008 BOLT HEX,SOCKET HEAD 3
22 91312-05016 BOLT HEX,SOCKET HEAD 4
23 91312-05020 BOLT HEX,SOCKET HEAD 6
24 91312-05025 BOLT HEX,SOCKET HEAD 6
25 91312-06025 BOLT HEX,SOCKET HEAD 4
1
4
Head
X-Ray Head
KLC-1304
31
31
2
3
3
11
24
24
26
38
29
29
30
28
28
34
13
31
4
6
26
8
38
34
34
7
7
34
5
10
9
30
30
30
30
30
22
40
32
28
28
35
39
19
17
21
42
18
20
22
1
31
35
26
27
33
36
32
18
15
18
14
20
20
2938
OLD
25
17
16
21
23
32
18
15
19
23
14
37
20
OLD
41
12
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLC-M71A1-00 PLATE SLIDE 1
2 KLC-M71A2-00 PLATE BODY 1
3 KLC-M71A3-00 PLATE A3 2
4 KLC-M71A4-00 PLATE A4 1
5 KLC-M71A5-01 BRKT.A5 1
6 KLC-M71A6-01 BRKT.A6 1
7 KLC-M71A7-00 BRKT.A7 2
8 KLC-M71A8-00 BRKT.A8 1
9 KLC-M71A9-01 BRKT.A9 1
10 KLC-M71AA-00 BRKT.AA 1
11 KLC-M71AB-01 BRKT.AB 1
12 KLC-M71FA-00 BLOCK SPRING 1 NG MMX0021-2015/11/20
13 KLC-M71H1-00 X-RAY SOURCE 1
14 KLC-M71F1-00 BLOCK SPRING 2
14-1 KLC-M71F1-01 BLOCK SPRING 1 NG MMX0021-2015/11/20
15 KLC-M71F2-01 SHAFT 2
15-1 KLC-M71F2-02 SHAFT 2 NG MMX0021-2015/11/20
16 KLC-M71F3-00 SHAFT 2
16-1 delete MMX0021-2015/11/20
17 KLC-M71F4-00 STOPPER 2
17-1 KLC-M71FC-00 PLATE,STOPPER 2 NG MMX0021-2015/11/20
18 KLC-M71F5-01 TAPE 2
18-1 KLC-M71FD-00 LINEAR BUSH 6 NG MMX0021-2015/11/20
19 KLC-M71F6-00 ADJ.SPRING 2
19-1 KLC-M71FB-00 HOLDER,SHAFT 2 NG MMX0021-2015/11/20
20 KLC-M71F7-00 SPRING 2
20-1 KLC-M71F7-01 SPRING 6 NG MMX0021-2015/11/20
21 KLC-M71F8-00 BLOCK SPRING 2
21-1
KLC-M71F8-01 BLOCK SPRING 2 NG MMX0021-2015/11/20
22 KLC-M71F9-00 BRKT.,F9 2
22-1 KLC-M71F9-01 BRKT.,F9 2 NG MMX0021-2015/11/20
23 95302-10700 NUT HEXAGON 6
23-1 delete MMX0021-2015/11/20
24 91312-04005 BOLT HEX.SOCKET HEAD 3 M4X5
25 91312-04010 BOLT HEX.SOCKET HEAD 6 M4X10
26 91312-05006 BOLT HEX.SOCKET HEAD 8 M5X6
27 91312-05010 BOLT HEX.SOCKET HEAD 4 M5X10
28 91312-05016 BOLT HEX.SOCKET HEAD 12 M5X16
29 91312-06010 BOLT HEX.SOCKET HEAD 8 M6X10
29-1 91312-06010 BOLT HEX.SOCKET HEAD 4 M6X10 OK MM30248-2015/6/2
30 91312-06012 BOLT HEX.SOCKET HEAD 20 M6X12
31 91312-06016 BOLT HEX.SOCKET HEAD 10 M6X16
32 91312-06020 BOLT HEX.SOCKET HEAD 4 M6X20
33 92902-05200 WASHER PLAIN 2
34 92902-06200 WASHER PLAIN 8
35 99480-05014 PIN,PARALLEL 4
36 99480-06012 PIN,PARALLEL 4
37 90990-01J011 BOLT, HEX. SOCKET HE 4
38 90990-01J032 BOLT,HEX.SOCKET HEAD 4 MM30248-2015/6/2
39 91312-05008 BOLT,HEX.SOCKET HEAD 2 MMX0021-2015/11/20
40 KLC-M71FE-00 BRKT.,FE 1 MMX0021-2015/11/20
41 92902-08200 WASHER,PLAIN 2 MMX0021-2015/11/20
42 92012-08020 BOLT,BUTTON HEAD 2 MMX0021-2015/11/20
2
4
HZ-axis
X-Ray Head
KLC-1304
9
26
5
17
31
21
11
32
8
13
3
26
25
28
28
28
10
10
2
2
20
16
19
7
6
24
29
18
27
12
33
1
27
32
29
18
22
23
14
15
28
30
30
4
22
OLD
7
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLC-M71B1-00 PLATE BASE 1
2 KLC-M71B2-00 BLOCK LM 2
3 KLC-M71B3-00 BLOCK BRG. 1
4 KLC-M71B4-00 BLOCK BRG. 1
5 KLC-M71B5-00 BALL SCREW 1
6 KLC-M71B6-00 PULLEY SHAFT 1
7
KLC-M71B7-01 CLAMP LOCK 1 4 bolts OK ML20059-2014/3/7
KLC-M71B7-00 CLAMP LOCK 1 6 bolts
8 KLC-M71B8-00 BRKT.STOPPER 1
9 KLC-M71B9-00 COVER SCREW 1
10 KLC-M71BA-01 LM RAIL & GUIDE 2
11 KLC-M71BB-00 BLOCK NUT 1
12 KLC-M71BC-00 PLATE BC 1
13 KX9-M22G1-01 PLATE,BRG 1
14 KE2-M2274-0B UNIT BRG. 1
15 KX8-M22J2-00 DAMPER,ORG 1
16 KHW-M264G-00 SPACER 1
17 KW6-M711H-00 GREASE NIPPLE 1
18 KHN-M22F8-00 WASHER,SWR08 8
19 90990-15J007 NUT,HEXAGON 1
20 90990-26J004 BEARING 1
21 90990-33J021 BOLT,STOPPER 2
22 91312-04005 BOLT HEX.SOCKET HEAD 4 M4X5
23 91312-04010 BOLT HEX.SOCKET HEAD 4 M4X10
24 91312-04020 BOLT HEX.SOCKET HEAD 4 M4X20
25 91312-05014 BOLT HEX.SOCKET HEAD 5 M5X14
26 91312-06016 BOLT HEX.SOCKET HEAD 8 M6X16
27 91312-06020 BOLT HEX.SOCKET HEAD 14 M6X20
28 91312-06025 BOLT HEX.SOCKET HEAD 22 M6X25
29 91312-08030 BOLT HEX.SOCKET HEAD 8 M8X30
30 92A08-06310 SCREW,SET 1
31 95302-06700 NUT HEXAGON 2
32 99480-06012 PIN,PARALLEL 6
33 99480-06030 PIN, PARALELL 2
