– 101 –
POSITIONING SECTION
No. Part No. Part Name Qty. Detail
101 KYA-M3J0K-00 BRACKET_FIBER 2
102 KYB-M3J1D-00 HOLDER_BKT_R 1
103 KYB-M3J1E-00 HOLDER_BKT_L 1
104 KYB-M3J1F-00 HOLDER_R 1
105 KYB-M3J1G-00 HOLDER_L 1
106 KYB-M3J1N-00 AMP-FIBER 1
108 90990-02J022 SCREW,SET 2
109 91312-03008 BOLT,HEX.SOCKET HEAD 8
1907-005
