– 130 – G1 5 Nozzle Shaft, V accum Filter 1907-005 496 490 496 490 450 431 447 430 A 486 486 486 474 42 5 406 407 411 420 433 426 405 407 411 432 494 409 413 421 466 421 428 444 476 445 DET AIL A See Fig. G1-6 Key No.501…
– 129 –
HIGH SPEED HEAD (DDH V9)
1907-005
No. Part No. Part Name Qty. Detail
302 KYA-M7019-00 MOTOR_NS 1 M32
303 KYA-M701C-00 MOTOR_NL 1 M33
304 KYA-M701N-00 ASSY_NS_MOTOR 1
305 KYA-M701P-00 ASSY_NL_MOTOR 1
310 KYB-M7031-00 ASSY_NL_BALL_SCREW 1
312 KYB-M700M-00 BALL_SCREW_NL 1
313 KYB-M702N-00 ASSY_NS_T-PULLEY 1
314 KYB-M704C-00 PULLEY_TIMING 1
315 KYB-M704B-00 PULLEY_TIMING 1
316 KYB-M705K-00 BELT_TIMING 1
327 91312-03020 BOLT,HEX.SOCKET HEAD 1
338 KYB-M7042-00 BLOCK 1
340 KYB-M7041-00 PLATE 1
341 KYB-M702J-00 SENSOR_DOG_NL 1
343 KYA-M700A-00 BASE_HEAD 1
352 KYB-M700R-00 SUPPORT_UNIT_NL 1
353 KYB-M702H-00 BLOCK_NL_BEARING 1
354 KYB-M702P-00 SPRING_COMP_NL 1
355 KYB-M702G-00 BLOCK_NL_SPRING 1
365 KYB-M700N-00 BEARING_NL 1
370 KYB-M702C-00 COUPLING 1
371 KYA-M700Y-00 ASSY,SENSOR B0210 1 B0210
376 90112-02J004 BOLT,HEX.SOCKET HEAD 2
378 90112-02J010 BOLT,HEX.SOCKET HEAD 1
379 90112-2AJ006 BOLT,HEX.SOCKET HEAD 2
380 90112-2AJ010 BOLT,HEX.SOCKET HEAD 3
381 90112-2AJ016 BOLT,HEX.SOCKET HEAD 1
383 91312-03008 BOLT,HEX.SOCKET HEAD 1
384 91312-03010 BOLT,HEX.SOCKET HEAD 5
385 91312-03012 BOLT,HEX.SOCKET HEAD 4
387 91312-05016 BOLT,HEX.SOCKET HEAD 2
391 90990-02J019 SCREW,SET 2
392 90189-02J2A6 NUT,HEXAGON 1
393 95302-03600 NUT,HEXAGON 2
3A1 90171-02J2A6 WASHER,PLAIN 1
3A3 92902-03200 WASHER,PLAIN 4
3A6 KYB-M7045-00 BOLT_HEX-SCT 4
3A9 92902-06200 WASHER,PLAIN 4
– 131 –
HIGH SPEED HEAD (DDH V9)
1907-005
No. Part No. Part Name Qty. Detail
405 KYB-M701U-00 ACCESSORY_SV 15 Y0401-0415
406 KYB-M704D-00 AIR_CLEAN_EQPT 30
407 KYB-M701W-00 ASSY_FILTER-HH 15
409 KYB-M700V-00 ASSY_NOZZLE_SHAFT 15
411 KYA-M701U-00 ASSY_BLOCK_TOP 15
413 KYA-M7017-00 SENSOR_PELEC 1 U03, B0413T, B0413R
420 KYB-M7035-00 ASSY_SEAL_HOLDER 15
421 KYB-M704E-00 SEAL 30
425 90990-01J114 BOLT,HEX.SOCKET HEAD 30
426 KYB-M702B-00 SEAL 30
428 KYB-M704F-00 SEAL 15
429 KYA-M7000-00 ROTOR_UPPER 1
430 KYA-M700J-00 ROTOR_LOWER 1
431 KYA-M7024-00 BRACKET_LN_SENS 1
432 KYB-M702A-00 DISK 1
433 KYB-M701R-00 HOLDER 15
444 KYB-M702R-00 SPRING_COMP_NOZ 15
445 KYB-M7028-00 SEAL 45
447 KYB-M7029-00 DISK 1
450 KYA-M7025-00 BLOCK_LINE_SENS 1
466 KYB-M702F-00 HOLDER 15
474 90990-01J117 BOLT,HEX.SOCKET HEAD 2
476 90112-02J004 BOLT,HEX.SOCKET HEAD 18
486 90990-01J031 BOLT,HEX.SOCKET HEAD 8
490 91317-03008 BOLT HEX.SOCKET HEAD 4
494 91317-03035 BOLT,HEX.SOCKET HEAD 2
496 92907-03200 WASHER,PLAIN 4
