P-327-005_SIGMA-F8S.pdf - 第184页
– 178 – H1 8 Cable 1907-005 B136 B302 B201 B301 B304 B303 B140 B130,131 B132,133 B134,135 B141 B305 B306 B136T 614 615 61 1 617 616
– 177 –
SINGLE CONVEYOR SECTION
1907-005
No. Part No. Part Name Qty. Detail
501 KYA-M915W-00 TUBE_D4 1
502 KYA-M915X-00 TUBE_D32 1
503 KYB-M919J-00 TUBE_D6 1
– 179 –
SINGLE CONVEYOR SECTION
1907-005
No. Part No. Part Name Qty. Detail
611 KYA-M910P-00 HNS,CONV-IO-U 1
614 KYA-M911B-00 HNS,SLOW-SENSOR1 1
615 KYA-M911C-00 HNS,SLOW-SENSOR2 1
616 KYA-M911D-00 HNS,BU-PIN-SENSOR-R 1
617 KYA-M911E-00 HNS,BU-PIN-SENSOR-T 1
641 KYY-M911A-00 PANEL 1
642 KYB-M91AK-00 PCB-MOUNT 1 U08(UB95)
644 KYB-M913W-00 UNIT-DRIVER 1 A41
645 90990-11J012 SCREW,PAN HEAD WW 4
646 90990-11J017 SCREW,PAN HEAD WW 4
648 KYY-M911L-00 HNS,CONV-INTL-D 1
649 KYY-M910N-00 HNS,CONV-IO-D 1
