1 Introduction Installation Manual
Edition 05/2011 SIPLACE Pro 9.3
5
Note:
Further instructions on installing operating systems, databases, networks and on backing up data
can be found in the ".\SIPLACE NET\NAVIGATION GUIDE" directory on the Support Media DVD
no.1. 1
1.3 System requirements
Notes:
– SIPLACE Pro requires an NTFS partition to be installed on. FAT or FAT32 file systems
are not supported.
– SIPLACE Pro 9.3 requires the license manager 2.2 SP2 for its operation.
– New licenses are required for operating SIPLACE Pro 9.3 after an update from SIPLACE
Pro 8.0. The existing licenses are still valid after an update from SIPLACE pro 9.2 to SI-
PLACE Pro 9.3.
– The Microsoft .NET Framework 3.5 SP1 is required.
– With the installation of SIPLACE Pro it is not possible to use operating systems or data-
base versions that are no longer supported:
Windows 2000 Server/ Windows 2000 Professional and former versions,
Microsoft SQL Server 2000 SP4/ MSDE SP4 and former versions.
– A mixed operation of different SQL server versions (2005 / 2008) is not supported.
– SQL Server 64 Bit versions are only supported on Windows 64 Bit operating systems.
– The Support Media DVD included in the installation package checks the necessary sys-
tem requirements of your system and installs these. Amongst others e.g. Microsoft .NET
Framework, the License Manager and the Error Reporting tool.
–It is required to use the Support Media V1.12.
Installation Manual 1 Introduction
SIPLACE Pro 9.3 Edition 05/2011
6
1.3.1 Computer
1
Server / Database Computer System
Software (required) Hardware (recommended)
– Preferred:
Windows Server 2008 R2 SP1 (64 Bit)
– Compatible:
Windows Server 2003 SP2 (32 and 64 Bit) 1
Windows Server 2003 R2 (32 and 64 Bit) 1
Windows Server 2008 SP2 (32 and 64 Bit) 1
– Preferred:
Microsoft SQL Server 2008 R2 /
Express Edition R2 (64 Bit)
– Compatible:
Microsoft SQL Server 2005 SP4/
Express Edition SP4 (32 and 64 Bit) 1
Microsoft SQL Server 2008 SP1 /
Express Edition SP1 (32 and 64 Bit) 1
Microsoft SQL Server 2008 R2 /
Express Edition R2 (32 Bit) 1
– Microsoft .NET Framework 3.5 SP1
– e.g. 2x Intel E5520 2.26 GHz 8MB
– 4096 MB RAM (2048 MB at least), depending
on the complexity of the data content.
– HDD SATA II 500GB
– Optional Backup drive (e.g. DAT, DVD)
– 21" monitor (19" monitor at least)
– Optional: Uninterruptible power supply
1 Introduction Installation Manual
Edition 05/2011 SIPLACE Pro 9.3
7
1
1.3.2 Resource Requirements
1
Client Computer System
Software (required) Hardware (recommended)
– Preferred:
Windows 7 SP1 (64 Bit)
– Compatible:
Windows XP SP3 (32 Bit) 1
Windows Vista SP2 (32 and 64 Bit) 1
Windows 7 SP1 (32 Bit) 1
– Microsoft .NET Framework 3.5 SP1
– e.g. 1x Core 2 Duo E8500
Note: The SiCluster Professional GUI e.
g. uses multi core processors during parallel
optimization.
– 4096 MB RAM (2048 MB at least),
depending on the complexity of the data
content.
– HDD SATA II 250GB
– 21" monitor (19" at least) with a screen
resolution of at least 1024 x 1280 pixel
(small fonts)
Hard disk Main Memory
– Windows and program files:
= ~4000 MB
– Database and Backup:
= ~Number of optimized recipes x 20 MB
– Windows:
= ~200 MB.
– SQL Server:
= typically 500 MB (RAM requirement
depends on the data volume)
– LineControl Server:
= ~100 MB
– For every client (Desk, LineControl GUI,
Optimizer Toolkit) each:
= ~100 MByte + number of recipes x
number of placement positions / 1000 MB
