Scope of Delivery
Software Requirements
Installation Manual SIPLACE Traceability 4.0 7
2
2 Scope of Delivery
Scope of Delivery
▪ SIPLACE Traceability Basic License V4.x (license only) [00117302]
or
▪ SIPLACE Traceability Upgrade-License V4.x (license only) [00117303]
▪ SIPLACE Traceability Machine Connection (full version [169578] or upgrade [169579])
▪ SIPLACE MES Process Interlocking License [116959]
▪ SIPLACE Traceability V4.x Media Package [00117301]:
– 1 Traceability 4.0 CD
▪ SIPLACE NET Support Version 2.0 [00117951]
▪ Basic documents:
– Installation Manual SIPLACE Traceability 4.0 (item no.: 00197718-01 [English])
– Software Version Description SIPLACE Traceability 4.0 (item no.: 00197717-01 [English, Ger-
man])
– User Guide SIPLACE Traceability 4.0 1 (item no.: 00197715-01 [German] / 00197715-01 [Eng-
lish])
– SIPLACE Support Media Installation Manual, item no. [00197214-xx]
2.1
2.1 Software Requirements
Software Requirements
To run the Traceability 4.0 system the following installations have to be performed:
▪ SIPLACE Pro 12.0 (preferred) 11.2 (compatible)
▪ SIPLACE Setup Center 7.0 (preferred), 6.3 (compatible)
▪ SIS 12.0 (preferred), 11.2 (compatible)
▪ Trace Service 4.0
▪ SIPLACE Studio
▪ Trace Monitor 4.0
▪ Station software:
– 407.05 (SIPLACE 80 F4, F4-6, S20; F5, F5 HM, S23)
– 505.05 SP2 (SIPLACE S25 HM, S27 HM, HS50, HS 50+, HS60, HF, HF3)
– 605.03 SP2(SIPLACE X2, X3, X4; D1, D2, D3, D4)
– 705.x (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, DX1, DX2, DX4)
– 706.0 (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, SX1 V2, SX2 V2, DX1, DX2, DX4)
– 706.1 (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, X4 Si, X4S, X3S, SX1 V2, SX2 V2, DX1, DX2,
DX4)
– 707.xx (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, X4 Si, X4 S, X3 S, X2 S, X4 S micron, X4i S
micron, SX1 V2, SX2 V2, DX1, DX2, DX4)
– 708.xx (SIPLACE X2, X3, X4, X4I, SX1, SX2, SX4, X4 Si, X4 S, X3 S, X2 S, X4 S micron, X4i S
micron, SX1 V2, SX2 V2, DX1, DX2, DX4)
NOTICE
Navigation Guide
Please use the document “Navigation Guide for the Installation Procedure of SIPLACE Soft-
ware Systems” (Item no. 00195050-xx) to guide you through the documentation. The Naviga-
tion Guide and all the other documents referred to can be found on one of the Support Media
DVDs (item no. 00388693-xx or 00388694-xx), supplied with each software product.
