NPM-TT_Parts list ( mechanical ).pdf - 第34页
1-F 本 体部 :NPM-TT M ai n Bod y:N PM - TT パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N6 1013 637 9AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S11 ( KN610136379AA-05-6 )
Ref
No.
Remarks
R
1
Q'ty
1-E
本
体部
:NPM-TT
Main Body:NPM-TT
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610136379AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
WASHER
6
1 N210148533AA
BRACKET
2
3 N210161869AA
PLATE
1
4 N210091217AA
BRACKET
4
5 N210147136AA
BRACKET
1
6 N210142913AC
PUMP KIT
1
7 N610124205AC
S
JOINT
1
8 KXF0E4LPA00 KQ2ZT08-02S
JOINT
1
9 KXF0A0EAA00 KQ2R06-08
JOINT
1
10 KXF0DZKRA00 KQ2P-08
SPACER
6
11 N510017103AA CB-504E
CLIP
3
12 KXF0E0V6A00 NK-12N
FAN-GUARD
1
13 KXF07S8AA00 109-619E
FAN-GUARD
1
14 KXFP007AA00 109-620
GROMMET
6
16 N510061330AA C-30-SG-52A-EP-UL
FAN
1
17 N510061509AA
S
109-642-16
CABLE-SUPPORT
13
18 N510059360AA KR8G5-5
BOLT
13
19 N510017538AA
SSS 003 Hexagon socket button head screw M5X10-10.9 A2J (Trivalent)
S10
--
( KN610136379AA-05-5 )
1-F
本
体部
:NPM-TT
Main Body:NPM-TT
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610136379AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S11
( KN610136379AA-05-6 )
Ref
No.
Remarks
R
1
Q'ty
1-F
本
体部
:NPM-TT
Main Body:NPM-TT
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610136379AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210160942AB
BRACKET
1
2 N210142890AA
PLATE
2
3 N210153484AA
JOINT
1
4 KXF0E1QFA00 KQ2D06-00
JOINT
1
5 N431KQ2N0608 KQ2N06-08
MANIFOLD
2
6 N510061933AA M4GA110-E2NHS-2-FL463361-3-ST
VALVE
2
7 N510055190AA 4GA130-M5-A2NS-FL432737-3-ST
MANIFOLD
1
8 N510051935AA VV3QZ12-02-X60V
REGULATOR
1
9 N510037363AA IR2000-02-R-DIL00073
REGULATOR
1
10 N510037364AA AR20-02H-1Y-X2276
REGULATOR
1
11 N510037365AA AR20-02H-Y-X2299
SWITCH
1
12 N510061332AA ZSE30AF-C6H-N-MA1
GAUGE
1
13 N510040253AA GZ46-K-01-C
GAUGE
1
14 N510037366AA G46-2-01-C
GAUGE
1
15 N510016399AA G46-10-01-C
JOINT
3
16 KXF0E0FGA00 KQ2LF06-01
REGULATOR
1
17 N510060652AA AC30X-03-X2723
SWITCH
1
18 N510061333AA ISE30A-C4H-N-MB
HOSE
1
19 N510002541AA OUA8X12-5M-03B
JOINT
5
20 KXF0A0DAA00 KQ2X06-08
JOINT
1
21 KXF09ZBAA00 KQ2P-06
JOINT
1
22 N510008502AA KQ2D08-00
JOINT
1
23 N431KQ2N0899 KQ2N08-99
JOINT
4
24 KXF0E1PXA00 KQ2LU06-00
BRACKET
2
25 N210160943AC
JOINT
2
26 KXF0DUBAA00 KK3S-08E
S12
--
( KN610136379AA-05-6 )
