More Information at the
product web page
Station
Watch the
product video
Video Guide
X
x
This Plug & Play Guide corresponds to the following references:
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - negro plano
200 mm
300 mm
1
2
Ref.
ALE-908VB (100 V)
ALE-108VB (120 V )
ALE-208VB (230 V)
ALE-910VB (100 V) *
ALE-110V B (120 V ) *
ALE-210VB (230 V) *
ALE-912VB (100 V)
ALE-112VB (120 V )
ALE-212VB (230 V)
ALE-915VB (100 V)
ALE-115VB (120V)
ALE-215VB (230 V)
ALE-916VB (100 V)
ALE-116VB (120 V )
ALE-216VB (230 V)
Ref. Ref.
ALE-904B (100 V)
ALE-104B (120 V)
ALE-204B (230 V)
ALE-910B (100 V)
ALE-110B (120 V)
ALE-210B (230 V)
ALE-905B (100 V)
ALE-105B (120 V)
ALE-205B (230 V)
ALE-912B (100 V )
ALE-112B (120 V)
ALE-212B (230 V)
ALE-906B (100 V)
ALE-106B (120 V)
ALE-206B (230 V)
ALE-915B (100 V)
ALE-115B (120 V)
ALE-215B (230 V)
ALE-907B (100 V )
ALE-107B (120 V)
ALE-207B (230 V)
ALE-916B (100 V)
ALE-116B (120 V)
ALE-216B (230 V)
ALE-908B (100 V)
ALE-108B (120 V)
ALE-208B (230 V)
ALE-918B (100 V)
ALE-118B (120 V)
ALE-218B (230 V)
More Information at the
product web page
Station
This Plug & Play Guide corresponds to the following references:
ALE
Automatic-Feed Soldering Station
Station with Solder Wire Perforation Station without Solder Wire Perforation
* Available to order on
the JBC Web site.
All other references
upon request.
1
2
Purchased Station
Ref.
Control Unit *
Ref.
Suitable
for Solder Wire:
ALE-908VB (100 V)
ALE-108VB (120 V )
ALE-208VB (230 V)
ALE-908UVB (100 V)
ALE-108UVB (120 V)
ALE-208UVB (230 V)
Ø 0.8 mm / Ø 0.032 in
ALE-910VB (100 V)
ALE-110V B (120 V )
ALE-210VB (230 V)
ALE-910UVB (100 V )
ALE-110UVB (120 V)
ALE-210UVB (230 V)
Ø 1.0 mm / Ø 0.040 in
ALE-912VB (100 V)
ALE-112VB (120 V )
ALE-212VB (230 V)
ALE-912UVB (100 V)
ALE-112U VB (120 V )
ALE-212UVB (230 V)
Ø 1.2 mm / Ø 0.047 in
ALE-915VB (100 V)
ALE-115VB (120V)
ALE-215VB (230 V)
ALE-915UVB (100 V)
ALE-115UVB (120V )
ALE-215UVB (230 V)
Ø 1.5 mm / Ø 0.060 in
ALE-916VB (100 V)
ALE-116VB (120 V )
ALE-216VB (230 V)
ALE-916UVB (100 V )
ALE-116UVB (120 V)
ALE-216UVB (230 V)
Ø 1.6 mm / Ø 0.063 in
With Solder Wire Perforation
Packing List:
The following items are included in all purchased station references (1 unit of each item):
*One of the listed control unit
references is included according
to the purchased station
reference.
ALE250 Automatic-Feed Soldering Iron
Ref. ALE250-B
ALES Stand for ALE250
Automatic-Feed Soldering Iron
Ref. ALE-SB
C250403 Conical Bent Cartridge Ø 1
Ref. C250403
Note:
A solder wire guide kit is included inside the control unit package and the guide wheels are
already installed in the control unit.
Other soler wire guide kits for other solder wire diameters are available at www.jbctools.com/
solder-wire-guide-product-2098.html
With Solder Wire Perforation
Packing List:
GALExxV
Solder Wire Guide Kit for ALE250
with perforation
GALExxD
Solder Wire Guide Kit for ALE250
Content*
2
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - negro plano
200 mm
300 mm
Station
Ref.
Control Unit *
Ref.
Suitable
for Solder Wire:
ALE-904B (100 V)
ALE-104B (120 V)
ALE-204B (230 V)
ALE-904UB (100 V)
ALE-104UB (120 V )
ALE-204UB (230 V)
wire Ø 0.38 - 0.4 mm / 0.015 - 0.016 in
ALE-905B (100 V)
ALE-105B (120 V )
ALE-205B (230 V)
ALE-905UB (100 V)
ALE-105UB (120 V )
ALE-205UB (230 V)
wire Ø 0.45 - 0.56 mm / 0.018 - 0.022 in
ALE-906B (100 V)
ALE-106B (120 V)
ALE-206B (230 V)
ALE-906UB (100 V)
ALE-106UB (120 V)
ALE-206UB (230 V)
wire Ø 0.6 - 0.64 mm / 0.023 - 0.025 in
ALE-907B (100 V )
ALE-107B (120V )
ALE-207B (230 V)
ALE-907UB (100 V)
ALE-107UB (120V )
ALE-207UB (230 V)
wire Ø 0.7 - 0.78 mm / 0.028 - 0.031 in
ALE-908B (100 V)
ALE-108B (120 V )
ALE-208B (230 V)
ALE-908UB (100 V)
ALE-108UB (120 V)
ALE-208UB (230 V)
wire Ø 0.8 - 0.82 mm / 0.032 - 0.033 in
ALE-910B (100 V)
ALE-110B (120 V)
ALE-210B (230 V)
ALE-910UB (100 V )
ALE-110UB (120 V)
ALE-210UB (230 V)
wire Ø 0.9 - 1.1 mm / 0.036 - 0.044 in
ALE-912B (100 V )
ALE-112B (120 V )
ALE-212VB (230 V)
ALE-912UB (100 V)
ALE-112UB (120 V)
ALE-212UB (230 V)
wire Ø 1.14 - 1.27 mm / 0.045 - 0.051 in
ALE-915B (100 V)
ALE-115B (120 V )
ALE-215B (230 V)
ALE-915UB (100 V)
ALE-115UB (120 V )
ALE-215UB (230 V)
wire Ø 1.5 - 1.57 mm / 0.06 - 0.063 in
ALE-916B (100 V)
ALE-116B (120 V)
ALE-216B (230 V)
ALE-916UB (100 V)
ALE-116UB (120 V )
ALE-216UB (230 V)
wire Ø 1.6 - 1.63 mm / 0.063 - 0.065 in
ALE-918B (100 V)
ALE-118B (120 V )
ALE-218B (230 V)
ALE-918UB (100 V )
ALE-118UB (120 V )
ALE-218UB (230 V)
wire Ø 1.8 mm / 0.073 in
Without Solder Wire Perforation
Packing List:
P405 Pedal
Ref. P-405
SCH Cartridge Holder
Ref. SCH-A
PLR195 Cartridge Extractor Plier
Ref. PLR195
The following items are included in all purchased station references (1 unit of each item):
*One of the listed control unit references is
included according to the purchased station
reference.
Content*
